ASTM A516 Grade 65|A516 Gr.65 STEEL PLATE



ASTM A516 standard specification for pressure vessel plates, carbon steel for moderate and lower- temperature service.

ASTM A516 plates 40mm and under in thickness is normally supplied in the as-rolled condition. The plates may be ordered normalized or stress relieved, or both. ASTM A516 grade plates over 40mm in thickness shall be normalized.



Supplementary Technology:   HIC Test | NACE MR0175 | Z15 | Z25 | Z35 | S1 | S2 | S3 | S4.1
S5 | S6 | S7 | S8 | S9| S11 | S12 | S14 | S17



Thickness: 6MM to 300MM,

Width: 1500mm to 4050mm,

Length: 3000mm to 15000mm

Gangsteel is specialized in supplying ASTM A516 steel plate in A516 grade 65. For more information of A516 grade 65 steel plates, please check them in following:





A516 Grade 65 Chemical Composition

Grade

The Element Max (%)

C

Si

Mn

P

S

A516 grade 65











Thick <12.5mm

0.24

0.13-0.45

0.79-1.30

0.035

0.035

Thick12.5-50mm

0.26

0.13-0.45

0.79-1.30

0.035

0.035

Thick50-100mm

0.28

0.13-0.45

0.79-1.30

0.035

0.035

Thick100-200mm

0.29

0.13-0.45

0.79-1.30

0.035

0.035

Thick>200mm

0.29

0.13-0.45

0.79-1.30

0.035

0.035

Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%





Grade



A516 Grade 65 Mechanical Property

Thickness

Yield

Tensile

Elongation

A516 grade 65

mm

Min Mpa

Mpa

Min  %

6-40

240

450-585

23%

40-100

240

450-585

19%

Shipbuilding steel plateAlloy steel platesHigh strength plateCarbon steel plateStainless steel plate







Equivalent steel grade of A516 grade 65

Europe

Belgium

Germany

France

Italy

Sweden

India

Japan





E St E315



Fe 460-2-KG

SS29,12,01







If you need more stock steel plates in pressure vessel steel plate, please click warehouse sizes.

 Related Grade: Related Grade:A516 Grade 55|A516 Grade 60|A516 Grade 65| A516 Grade 70
