GB/T 6653-2017 HP345 steel plate and strip for welded gas cylinders: ReL 345 MPa min, Rm 51
GB/T 6653-2017 HP325 steel plate and strip for welded gas cylinders: ReL 325 MPa min, Rm 49
GB/T 6653-2017 HP295 steel plate and strip for welded gas cylinders: ReL 295 MPa min, Rm 44
GB/T 6653-2017 HP265 steel plate and strip for welded gas cylinders: ReL 265 MPa min, Rm 41
GB/T 6653-2017 HP235 steel plate and strip for welded gas cylinders: ReL 235 MPa min, Rm 38
|
|
| |
GB/T 6653-2017 (issued 2017-12-29, effective 2018-09-01, replaces GB/T 6653-2008) specifies steel plates and strips for welded gas cylinders: hot-rolled 2.0 to 14.0 mm and cold-rolled 1.5 to 4.0 mm. It covers five grades, HP235, HP265, HP295, HP325 and HP345, named from the pinyin HP (welded cylinder) plus the minimum lower yield strength in MPa (235 to 345 MPa), with tensile strength from 380 to 620 MPa. Gangsteel produces and exports GB/T 6653 hot-rolled coil, pickled strip, cut plate, cold-rolled annealed sheet and circular blanks with EN 10204 3.1/3.2 certificates. See also EN 10120, GB/T 713, Boiler Steel Plate and Pressure Vessel Steel Plate.
GB/T 6653-2017 HP345 steel plate and strip for welded gas cylinders: ReL 345 MPa min, Rm 510-620 MPa. Gangsteel
GB/T 6653-2017 HP325 steel plate and strip for welded gas cylinders: ReL 325 MPa min, Rm 490-600 MPa. Gangsteel
GB/T 6653-2017 HP295 steel plate and strip for welded gas cylinders: ReL 295 MPa min, Rm 440-560 MPa. Gangsteel
GB/T 6653-2017 HP265 steel plate and strip for welded gas cylinders: ReL 265 MPa min, Rm 410-520 MPa. Gangsteel
