GB/T 713 / GB/T 713.2 covers non-alloy and alloy steel plates with specified temperature properties for boilers and pressure vessels. Gangsteel produces and exports the full GB/T 713.2 grade set: Q245R, Q345R, Q370R, Q420R, Q460R, 18MnMoNbR, 13MnNiMoR, 15CrMoR, 14Cr1MoR, 12Cr2Mo1R, 12Cr1MoVR, 12Cr2Mo1VR, 07Cr2AlMoR. Low-temperature grades such as 16MnDR belong to GB/T 713.3 / related standards, not this hub. See also ASTM A516, ASTM A387, Pressure Vessel Steel Plate.
|
| ||
GB/T 3531 (Steel plates for low temperature pressure vessels) covers C-Mn and Ni alloy plates for service roughly -196°C to below -20°C. Gangsteel produces and exports the full commercial GB/T 3531 set: 16MnDR, 15MnNiDR, 15MnNiNbDR, 09MnNiDR, 08Ni3DR, 06Ni9DR. Buyers still order under GB/T 3531; successor parts are GB/T 713.3 / GB/T 713.4. See also GB/T 713, ASTM A203, ASTM A353 / ASME SA353, ASTM A553 Type I, Pressure Vessel Steel Plate.
ASTM A533 / ASME SA533 Quenched & Tempered Alloy Steel Plates | ||
ASTM A533/A533M (ASME SA533) covers quenched and tempered Mn-Mo and Mn-Mo-Ni alloy steel plates for welded pressure vessels. ASTM designates Types A–E; commercial orders commonly say Grades A/B/C/D. Gangsteel produces and exports the full set Grades/Types A/B/C/D/E × Classes 1/2/3 (15 pages, per ASTM A533/A533M-24). See also ASTM A537, ASME SA302, ASTM A516, Pressure Vessel Steel Plate.
ASTM A553 / ASME SA553 7% 8% 9% Nickel Quenched & Tempered Plates | ||
ASTM A553/A553M (ASME SA553/SA553M) covers 9%, 8% and 7% nickel alloy steel plates, water quenched and tempered, for welded pressure vessels in cryogenic service. The current edition (A553/A553M-22) defines three types: Type I (9% Ni, Charpy at -320°F [-196°C]), Type II (8% Ni, -275°F [-170°C]) and Type III (7% Ni, -320°F [-196°C]). All three share 100–120 ksi [690–825 MPa] tensile, 85 ksi [585 MPa] min yield and 20% min elongation. Gangsteel produces and exports all three types. See also ASTM A353 / SA353, ASTM A203, GB/T 3531, ASTM A533, Pressure Vessel Steel Plate.
EN 10028-4 Nickel Alloy Steel Plates with Specified Low Temperature Properties | |||
| |||
EN 10028-4:2017 (supersedes EN 10028-4:2009) specifies flat products for pressure equipment made of nickel alloy steels with specified low-temperature impact properties. The current edition covers seven grades: 11MnNi5-3 (1.6212) and 13MnNi6-3 (1.6217) 0.5% Ni normalized grades for about -60°C, 15NiMn6 (1.6228) 1.5% Ni to -80°C, 12Ni14 (1.5637) 3.5% Ni to -100°C, X12Ni5 (1.5680) 5% Ni to about -120°C, and the 9% Ni grades X8Ni9 (1.5662, +NT640 / +QT640 / +QT680) and X7Ni9 (1.5663, +QT) for LNG service at -196°C. Gangsteel produces and exports all EN 10028-4 grades with EN 10204 3.1/3.2 certificates. See also ASTM A553, ASTM A353 / SA353, GB/T 3531, ASTM A533, ASTM A537, Pressure Vessel Steel Plate.
|
|
|||
GB/T 3531 06Ni9DR ~9% Ni cryogenic vessel plate, Charpy typically -196°C. Gangsteel produces and exports 06Ni9
GB/T 3531 08Ni3DR ~3.5% Ni low-temperature vessel plate, Charpy typically -100°C. Gangsteel produces and expor
GB/T 3531 09MnNiDR low-temperature vessel plate: Mn-Ni DR grade, Charpy typically -70°C. Gangsteel produces an
GB/T 3531 15MnNiNbDR low-temperature vessel plate: Mn-Ni-Nb DR grade, Charpy typically -50°C. Gangsteel produc
