Gangsteel Grade : |
|
|
Specification (mm) |
THK: 6 to 300, Width: 1500 to 4050, Length: 3000 to 27000 |
|
Standard: |
ASTM A283 Standard Specification is for Low and Intermediate Tensile Strength Carbon Steel Plates |
|
Approval By Third Party |
ABS, DNV, GL, CCS, LR , RINA, KR, TUV, CE |
|
Classification: |
Low and Intermediate Tensile Strength Carbon Steel Plates |
Supplementary Technology: HIC Test | NACE MR0175 | Z15 | Z25 | Z35| S2 | S3 | S5 | S6 | S8 | S15 | S97 | S97.1 |
Gangsteel is specialized in supplying ASTM steel plate in A283 Gr.C. For more information of A283 Grade C steel plates, please check them in following:
|
A283 Grade C Chemical Composition |
||||||
|
Grade |
The Element Max (%) |
|||||
|
C |
Si |
Mn |
P |
S |
Cu (min) |
|
|
0.24 |
0.15-0.40 |
0.90 |
0.035 |
0.04 |
0.20 |
|
Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%
|
Grade |
A283 Grade C Mechanical Property |
|||
|
Thickness |
Yield |
Tensile |
Elongation |
|
|
mm |
Min Mpa |
Mpa |
Min % |
|
|
t≦50 |
380-515 |
205 |
25 |
|
|
50<t≦200 |
380-515 |
205 |
22 |
|
Shipbuilding steel plate| Alloy steel plates| High strength plate| Carbon steel plate| Stainless steel plate
|
Equivalent steel grade of A283 Grade C |
||||||||
|
Europe |
Belgium |
Germany |
France |
Italy |
Sweden |
India |
Japan |
U.K |
|
S185，Fe 310-0 |
A 320 |
St 33 |
A 33 |
Fe 320 |
SS13,00,00 |
|
SS 330 |
|
If you need more stock steel plates in pressure vessel steel plate, please click warehouse sizes.
Related Grade: A283 Grade D | A283 Grade A |A283 Grade B | A283 GR.C
Gangsteel is specialized in supplying ASTM steel plate in A283 Gr.C.
Gangsteel is specialized in supplying ASTM steel plate in A283 Gr.A.
