Gangsteel is a leading manufacturer and global exporter of GB/T 4237 06Cr19Ni10N stainless steel hot-rolled coils, plates, and wide heavy plates. Known internationally as Grade 304N (nitrogen-enhanced variant of 304), 06Cr19Ni10N is an austenitic chromium-nickel stainless steel with controlled nitrogen addition (0.10–0.16%) that significantly improves yield strength, tensile strength, and pitting corrosion resistance while retaining the excellent formability, weldability, and general corrosion resistance of standard 304.

With 18% Cr, 8–11% Ni, and intentional nitrogen strengthening, 304N offers higher mechanical performance than conventional 304 (06Cr19Ni10) — especially in annealed condition — making it ideal for structural applications, pressure vessels, heat exchangers, and components requiring improved strength without sacrificing corrosion resistance or fabricability.

Produced under GB/T 4237-2015 (Stainless Steel Hot-Rolled Sheets and Strips), Gangsteel supplies 06Cr19Ni10N in thicknesses from 2 mm to 500 mm and widths up to 4200 mm — one of the widest hot-rolling capabilities in the industry. Our products are delivered in standard hot-rolled finishes No.1 (annealed & pickled) and 2D (annealed & pickled dull) and are exported worldwide to chemical processing, energy, food & beverage, architectural, rail transit, and heavy fabrication sectors.

Why Choose Gangsteel for 06Cr19Ni10N (304N) Hot-Rolled Stainless Steel?

Gangsteel’s wide heavy-plate rolling mills enable single-piece production of large-scale tanks, pressure vessel heads, and structural panels, reducing welds and improving integrity. We maintain strict control over nitrogen content and annealing to ensure consistent strength and corrosion performance.

Chemical Composition of GB/T 4237 06Cr19Ni10N

Standard Chemical Composition Table

Gangsteel precisely controls nitrogen at the higher end of the range to maximize strength gain while maintaining excellent corrosion resistance.

Mechanical Properties

Mechanical Properties Table (Annealed Condition)

Nitrogen strengthening provides higher yield without sacrificing elongation.

Physical Properties

Physical Properties Table

Equivalent Materials Comparison Table

Key Insight: 06Cr19Ni10N (304N) provides ~20–30% higher yield strength than standard 304 due to nitrogen addition, with similar corrosion resistance.

Manufacturing Process: Hot Rolled at Gangsteel

Gangsteel's hot-rolling process for 06Cr19Ni10N includes:

1. Electric arc furnace + AOD refining → precise nitrogen control
2. Continuous casting into wide slabs
3. Reheating to 1150–1250°C
4. Hot rolling on wide heavy-plate mills (up to 4200 mm width)
5. Controlled cooling, leveling, and descaling
6. Solution annealing + pickling for No.1 finish or shot blasting + pickling for 2D finish
7. Edge trimming, coil splitting, or cut-to-length

Thickness range: 2 mm – 500 mm Width range: up to 4200 mm Length: up to 18 m (plate) or coil form

Finishes: No.1 (annealed & pickled), 2D (annealed & pickled dull)

Available Forms, Sizes, and Specifications

• Hot-rolled coils: 2.0–25.0 mm thick, up to 4200 mm wide
• Hot-rolled plates: 2.0–500 mm thick, up to 4200 mm wide × 18 m long
• Cut-to-size plates, slit coils, custom blanks

All compliant with GB/T 4237-2015; optional third-party certification (SGS, TUV, BV).

Key Applications of 06Cr19Ni10N (304N) Hot-Rolled Products

• Pressure vessels and storage tanks requiring higher strength
• Heat exchangers and chemical processing equipment
• Food and pharmaceutical hygienic vessels
• Architectural structural components and rail transit parts
• High-strength welded pipes and fittings
• Cryogenic and low-temperature applications

Advantages of Choosing 06Cr19Ni10N (304N)

• 20–30% higher yield strength than standard 304
• Excellent general corrosion resistance in mild environments
• Superior weldability and formability
• Good strength and toughness from cryogenic to elevated temperatures
• Non-magnetic annealed; easy to clean and polish
• Cost-effective upgraded performance vs. 304
• Wide global acceptance and recyclability

Corrosion and Oxidation Resistance

Forms stable Cr oxide layer; resists rust in fresh water, mild acids, organics, and atmospheres. Nitrogen addition slightly improves pitting resistance. Oxidation resistance up to ~870°C intermittent.

Weldability and Fabrication

Excellent weldability with TIG/MIG/resistance/laser; low carbon minimizes sensitization. Use ER308/ER308L fillers. High ductility supports complex forming.

Why Choose Gangsteel for GB/T 4237 06Cr19Ni10N?

• Industry-leading width (up to 4200 mm) and thickness (up to 500 mm)
• Full traceability and third-party inspection
• Competitive pricing with large-scale production
• Fast lead times and global export expertise
• Technical support for welding, forming, and application

Quality Assurance and Certifications

Every heat is tested for chemistry, mechanical properties, surface quality, and dimensions. Full MTRs (EN 10204 3.1) and third-party certification available.

Packaging, Shipping, and Logistics

Coils eye-to-wall/eye-to-sky on steel pallets; plates bundled with skids; seaworthy export packaging with waterproof wrapping and edge protection.

FAQ

Q1: What is the main benefit of 304N (06Cr19Ni10N) over standard 304?

A: The intentional nitrogen addition increases yield strength by 20–30% while maintaining similar corrosion resistance and formability, making it ideal for structural and pressure-containing applications.

Q2: Can 06Cr19Ni10N be used in coastal or chloride-containing environments?

A: Suitable for mild exposure, but for long-term marine or high-chloride service, 316L or 444 is recommended for superior pitting resistance.

Q3: What finishes are available under GB/T 4237 for hot-rolled 304N?

A: Standard finishes are No.1 (annealed & pickled) and 2D (annealed & pickled dull). No.1 is most common for further processing.

Q4: What is the maximum width and thickness Gangsteel can produce for 06Cr19Ni10N?

A: Up to 4200 mm wide and 500 mm thick in hot-rolled plates; coils typically 2–25 mm thick.

Q5: Is 304N weldable? What filler should be used?

A: Yes, excellent weldability. Use ER308 or ER308L fillers for matching properties.

Q6: Does Gangsteel offer third-party inspection for GB/T 4237 304N material?

A: Yes — SGS, TUV, BV, or customer-nominated agencies are welcome at any stage.

Q7: What is the lead time for hot-rolled 06Cr19Ni10N coils or plates?

A: Standard sizes from stock: 7–15 days. Custom wide/heavy plates: 25–45 days depending on thickness and quantity.

Q8: Can Gangsteel provide 304N with BA or 2B finish?

A: Hot-rolled material is No.1 or 2D. For BA or 2B, we supply cold-rolled versions under GB/T 3280.

Contact Gangsteel today for real-time pricing, stock availability, samples, or custom specifications of GB/T 4237 06Cr19Ni10N (304N) stainless steel hot-rolled coils, plates, and strips. Let us support your next high-strength stainless project with premium nitrogen-enhanced solutions.
