316Ti Stainless Steel Chemical Resistance Chart PDF
Published: November 9, 2025 | Updated: November 9, 2025By Gangsteel Engineering Team – 25+ Years in Stainless Steel Export Excellence
In the specialized domain of stainless steels compliant with ASTM A240/A240M and ASME SA240/SA240M standards, 316Ti emerges as a titanium-stabilized austenitic grade whose chemical resistance is pivotal for applications in aggressive environments.
As a premier producer and exporter based in China, Gangsteel has supplied thousands of tons of 316Ti stainless steel, meeting ASTM A240/A240M specs for plates and sheets, to industries like petrochemical, pharmaceutical, and marine.
If you're seeking a chemical resistance chart in PDF format under ASME SA240/SA240M where compatibility with acids, bases, and solvents is critical, this article provides a detailed overview and downloadable insights. We'll explore 316Ti's resistance data, influenced by its unique composition, based on ASTM A240/A240M and ASME SA240/SA240M standards and our mill tests.
From our production lines, we've documented 316Ti's resistance: In a 2024 U.S. chemical plant, our 316Ti components under ASTM A240 /A240M showed excellent compatibility with dilute acids at 80°C, with rates <0.1 mm/year, as per client lab reports. Compliant with ASME SA240/SA240M for pressure apps, 316Ti's density of 8.00 g/cm³ supports stable performance. Let's delve into the chart, from composition to resistance data, with PDF download options, to equip you for informed selections.
Summary
316Ti stainless steel, compliant with ASTM A240/A240M and ASME SA240/SA240M, offers excellent chemical resistance with ratings like A (Excellent) for acetic acid and B (Good) for concentrated sulfuric, thanks to Ti stabilization preventing IGC. PREN 23-28 ensures strong pitting resistance in chlorides. Density 8.00 g/cm³, tensile 515 MPa min. Superior to 304 in acids/heat; similar to 316L but better high-temp. Download the PDF chart below for full data; Gangsteel stocks 1-200mm with certs.
Chemical Composition: Basis for Resistance
The chemical composition of 316Ti, as specified in ASTM A240/A240M and ASME SA240/SA240M, is optimized for chemical resistance, with titanium ensuring stability in corrosives.
|
Element |
% Range or Max |
Role in Chemical Resistance |
|---|---|---|
|
Carbon (C) |
0.08 max |
Low C with Ti binding enhances acid resistance. |
|
Manganese (Mn) |
2.00 max |
Minor role; aids in alkaline environments. |
|
Silicon (Si) |
0.75 max |
Improves resistance to oxidizing acids. |
|
Phosphorus (P) |
0.045 max |
Limited for better durability in phosphates. |
|
Sulfur (S) |
0.030 max |
Controlled to avoid sulfide attacks. |
|
Chromium (Cr) |
16.00-18.00 |
Forms passive film for general resistance. |
|
Molybdenum (Mo) |
2.00-3.00 |
Enhances pitting in chlorides/acids. |
|
Nickel (Ni) |
10.00-14.00 |
Boosts resistance to reducing acids. |
|
Titanium (Ti) |
5x(C+N) min, 0.70 max |
Stabilizes for resistance in sensitizing corrosives. |
|
Nitrogen (N) |
0.10 max |
Improves pitting resistance. |
|
Iron (Fe) |
Balance |
Base for overall compatibility. |
This composition under ASTM A240/A240M gives PREN 23-28 for broad resistance.
Gangsteel's 316Ti meets ASME SA240/SA240M for certified use.
Chemical Resistance Chart: PDF Data Summary
316Ti's chemical resistance, per ASTM A240/A240M and ASME SA240/SA240M, is excellent for many corrosives, with ratings based on lab tests (A=Excellent, B=Good, C=Fair, D=Poor).
Download the full PDF chart from our site for detailed data; below is a summarized table of common chemicals.
|
Chemical |
Rating |
Notes/Temp |
|---|---|---|
|
Acetic Acid (20%) |
A |
Excellent at RT-100°C. |
|
Acetic Acid (80%) |
B |
Minor effect up to 80°C. |
|
Acetic Acid, Glacial |
A |
Excellent; stable to boiling. |
|
Acetone |
A |
Excellent; no effect. |
|
Aluminum Chloride (20%) |
C |
Moderate in dilute; avoid concentrated. |
|
Ammonia (10%) |
A |
Excellent; no attack. |
|
Ammonium Hydroxide |
A |
Excellent up to boiling. |
|
Benzene |
B |
Minor effect; good for solvents. |
|
Chromic Acid (5%) |
A |
Excellent; oxidizing resistance. |
|
Citric Acid |
A |
Excellent in food acids. |
|
Hydrochloric Acid (20%) |
D |
Poor; avoid. |
|
Nitric Acid (20%) |
A |
Excellent; strong oxidizer. |
|
Phosphoric Acid (>40%) |
C |
Moderate; concentration-dependent. |
|
Sodium Hydroxide (20%) |
B |
Minor effect up to 50°C. |
|
Sulfuric Acid (10-75%) |
D |
Poor; avoid concentrated. |
Ratings from standard charts; 316Ti similar to 316 but better in heat. Full PDF includes 200+ chemicals.
For uns stainless steel plates, 316Ti offers broad resistance.
Mechanical Properties: Supporting Resistance
316Ti's mechanical properties, per ASTM A240/A240M and ASME SA240/SA240M, ensure durability in corrosive settings.
|
Property |
Minimum Value |
Typical Range |
Notes |
|---|---|---|---|
|
Tensile Strength (MPa) |
515 |
550-700 |
High for corrosive stress. |
|
Yield Strength (MPa) |
205 |
220-300 |
Good resistance to deformation. |
|
Elongation (%) |
40 |
45-55 |
Ductility in corrosive forming. |
|
Hardness (HRB max) |
95 |
80-90 |
Low for resistance to cracking. |
Properties enhance chemical resistance by preventing stress failures.
Physical Properties: Complementing Chart Data
Physical properties of 316Ti, compliant with ASTM A240/A240M and ASME SA240/SA240M, support its resistance in various chemicals.
|
Property |
Value |
Notes on Resistance |
|---|---|---|
|
Density (g/cm³) |
8.00 |
Consistent for immersion calcs. |
|
Melting Range (°C) |
1370-1400 |
High for hot acid resistance. |
|
Thermal Conductivity (W/m·K) |
14.6 (at 100°C) |
Aids dissipation in corrosives. |
|
Specific Heat (J/kg·K) |
500 |
Efficient in chemical cycling. |
|
Thermal Expansion (10^-6 /°C) |
16.5 (20-100°C) |
Low stress in heated chemicals. |
|
Modulus (GPa) |
193 |
Stiffness in corrosive loads. |
|
Electrical Resistivity (μΩ·cm) |
74 |
Moderate for non-reactive uses. |
These bolster 316Ti's chart ratings.
Corrosion Resistance: Chart Context
316Ti's resistance, per ASTM A240/A240M and ASME SA240/SA240M, is charted for acids (A in citric), bases (B in NaOH), salts (A in NaCl).
- Acids: Excellent in dilute; fair in concentrated.
- Bases: Good in alkaline.
- Salts: Excellent in chlorides with Mo.
Chart PDF includes ratings for 200+ chemicals.
Weldability and Fabrication: Chart-Relevant
316Ti is weldable, Ti aiding resistance in chart corrosives per ASTM A240/A240M. Fillers ER316L.
Gangsteel's 316Ti SA240 Type 316Ti maintains ratings post-weld.
Applications: Where Chart Applies
316Ti's chart suits chemical reactors (acid resistance), marine piping (salt A rating).
In Gangsteel's supply to U.S. pharma, chart-guided use in vinegar (A) endured.
Equivalents: Grades with Similar Chart
Equivalents: EN 1.4571 (similar resistance chart). For A240 GR 316Ti, chart matches.
Sourcing from Gangsteel: Stock and Pricing
Gangsteel offers 316Ti at $3,200-3,800/ton FOB. 1-200mm thick, ASME SA240 certs with chart data. Contact for PDF.
FAQ: 316Ti Stainless Steel Chemical Resistance Questions Answered
Q: What is the chemical resistance rating for 316Ti in acetic acid?
A: A (Excellent) for dilute acetic acid; B for 80% concentrations up to 80°C, per standard charts.
Q: How resistant is 316Ti to hydrochloric acid?
A: D (Poor) for concentrated HCl; avoid continuous use, as per resistance charts.
Q: What is 316Ti's rating in sulfuric acid?
A: D for 10-75% sulfuric acid; not recommended for concentrated, but B in dilute at RT.
Q: Is 316Ti resistant to nitric acid?
A: A (Excellent) for dilute nitric acid; good in boiling up to 50%.
Q: What is the chemical resistance of 316Ti in sodium hydroxide?
A: B (Minor effect) for 20% NaOH up to 50°C; good for alkaline.
Q: How does 316Ti perform in chlorine water?
A: C (Moderate effect); suitable for dilute but monitor for pitting.
Q: Where can I download the 316Ti chemical resistance chart PDF?
A: Gangsteel provides PDF charts with quotes; standard sources list ratings for 316 series, similar for 316Ti.
