Published: November 8, 2025 | Updated: November 8, 2025By Gangsteel Engineering Team – 25+ Years in Stainless Steel Export Excellence
In the specialized domain of stainless steels compliant with ASTM A240/A240M and ASME SA240/SA240M standards, 316Ti emerges as a titanium-stabilized austenitic grade renowned for its balanced material properties, making it ideal for corrosive and high-temperature environments.
As a premier producer and exporter based in China, Gangsteel has supplied thousands of tons of 316Ti stainless steel, meeting ASTM A240/A240M specs for plates and sheets, to industries like petrochemical, pharmaceutical, and marine.
If you're evaluating 316Ti for a welded tank or exhaust system under ASME SA240/SA240M where properties like strength, corrosion resistance, and thermal stability are critical, this overview provides comprehensive data. We'll explore its key material properties, influenced by its unique composition, based on ASTM A240/A240M and ASME SA240/SA240M standards and our mill tests.
From our production lines, we've observed 316Ti's property excellence: In a 2024 U.S. chemical facility, our 316Ti components under ASTM A240 /A240M exhibited superior IGC resistance at 600°C, maintaining properties for extended service, as per client evaluations. Compliant with ASME SA240/SA240M for pressure apps, 316Ti's density of 8.00 g/cm³ supports efficient designs. Let's delve into the overview, from composition to applications, to equip you for informed selections.
316Ti stainless steel, compliant with ASTM A240/A240M and ASME SA240/SA240M, offers tensile strength 515 MPa min, yield 205 MPa min, elongation 40% min, hardness 95 HRB max, and thermal conductivity 14.6 W/m·K, with Ti stabilization preventing IGC at 425-815°C. Density 8.00 g/cm³, PREN 23-28 for pitting resistance. Superior to 316 in high-temp durability, it's weldable and formable. Ideal for chemical reactors and marine; Gangsteel stocks 1-200mm with certs.
The chemical composition of 316Ti, as specified in ASTM A240/A240M and ASME SA240/SA240M, is optimized for material properties, with titanium ensuring stability against carbide formation.
|
Element |
% Range or Max |
Role in Material Properties |
|---|---|---|
|
Carbon (C) |
0.08 max |
Low C with Ti binding enhances corrosion resistance and maintains strength. |
|
Manganese (Mn) |
2.00 max |
Boosts ductility and toughness properties. |
|
Silicon (Si) |
0.75 max |
Improves oxidation resistance and thermal properties. |
|
Phosphorus (P) |
0.045 max |
Limited to preserve strength and corrosion traits. |
|
Sulfur (S) |
0.030 max |
Controlled for better weldability and surface properties. |
|
Chromium (Cr) |
16.00-18.00 |
Provides core corrosion resistance and strength. |
|
Molybdenum (Mo) |
2.00-3.00 |
Enhances pitting resistance, a key property. |
|
Nickel (Ni) |
10.00-14.00 |
Stabilizes austenite for superior ductility. |
|
Titanium (Ti) |
5x(C+N) min, 0.70 max |
Stabilizes for high-temp properties without IGC. |
|
Nitrogen (N) |
0.10 max |
Adds to strength properties. |
|
Iron (Fe) |
Balance |
Base for overall material characteristics. |
This composition under ASTM A240/A240M ensures balanced properties like high elongation.
Gangsteel's 316Ti meets ASME SA240/SA240M for reliable material use.
316Ti's mechanical properties, per ASTM A240/A240M and ASME SA240/SA240M, highlight its robustness for stress-prone apps.
|
Property |
Minimum Value |
Typical Range |
Notes on Properties |
|---|---|---|---|
|
Tensile Strength (MPa) |
515 |
550-700 |
High for load-bearing; stable at heat. |
|
Yield Strength (MPa) |
205 |
220-300 |
Good for deformation resistance. |
|
Elongation (%) |
40 |
45-55 |
Excellent for forming without fracture. |
|
Reduction of Area (%) |
Not specified |
50-60 |
Indicates toughness. |
|
Hardness (HRB max) |
95 |
80-90 |
Low for machinability. |
|
Brinell Hardness (HB max) |
217 |
160-190 |
Converted; aids wear resistance. |
|
Charpy Impact (J) |
Not req. |
100+ at RT |
High for impact apps. |
Properties remain stable up to 815°C with Ti.
For uns stainless steel plates, 316Ti offers superior data.
Physical properties of 316Ti, compliant with ASTM A240/A240M and ASME SA240/SA240M, complement its mechanical data.
|
Property |
Value |
Notes |
|---|---|---|
|
Density (g/cm³) |
8.00 |
Standard for weight calcs. |
|
Melting Range (°C) |
1370-1400 |
High for thermal apps. |
|
Thermal Conductivity (W/m·K) |
14.6 (at 100°C) |
Good dissipation. |
|
Specific Heat (J/kg·K) |
500 |
Efficient cycling. |
|
Coefficient of Thermal Expansion (10^-6 /°C) |
16.5 (20-100°C) |
Low distortion. |
|
Modulus (GPa) |
193 |
High stiffness. |
|
Electrical Resistivity (μΩ·cm) |
74 |
Moderate. |
These enhance 316Ti's material overview.
316Ti's corrosion resistance, per ASTM A240/A240M and ASME SA240/SA240M, is a standout property, with Ti preventing IGC.
316Ti is highly weldable, Ti preserving properties per ASTM A240/A240M. No preheat; good elongation for fab.
Gangsteel's 316Ti SA240 Type 316Ti excels in forming.
316Ti's properties suit chemical reactors (high elongation), food equipment (corrosion resistance), marine piping (strength).
In Gangsteel's supply to U.S. pharma, 316Ti properties endured without failure.
Equivalents: EN 1.4571 (similar properties). For A240 GR 316Ti, properties match.
Gangsteel stocks 316Ti at $3,200-3,800/ton FOB. 1-200mm thick, ASME SA240 certs with property data. Contact for overview.
Q: What are the material properties of 316Ti stainless steel?
A: 316Ti has tensile 515 MPa min, yield 205 MPa min, elongation 40% min, hardness 95 HRB max, density 8.00 g/cm³, and thermal conductivity 14.6 W/m·K, with Ti for high-temp stability.
Q: What is the density of 316Ti stainless steel?
A: The density of 316Ti is 8.00 g/cm³, standard for austenitic SS, supporting weight-efficient designs.
Q: What is the hardness of 316Ti stainless steel?
A: Maximum hardness is 95 HRB or 217 HB in annealed condition, soft for machining while maintaining properties.
Q: What is the yield strength of 316Ti stainless steel?
A: Minimum yield strength is 205 MPa, with typical 220-300 MPa, providing good deformation resistance.
Q: What is the tensile strength of 316Ti stainless steel?
A: Minimum tensile strength is 515 MPa, typically 550-700 MPa, stable at high temps due to Ti.
Q: What is the elongation of 316Ti stainless steel?
A: Minimum elongation is 40%, typically 45-55%, ensuring excellent ductility for forming.
Q: How do high temperatures affect 316Ti's material properties?
A: At 815°C, tensile retains >70%, elongation >30%; Ti prevents property loss from carbides.
