ASME SA283 Grade A Carbon Steel Plates: Specs & Pricing

What is asme sa283 grade a?

ASME SA283 Grade A is a low-carbon steel plate for low-strength structural applications, such as bridges, buildings, and storage tanks. It is normalized or as-rolled for good weldability and ductility, ideal for non-critical setups.



ASME SA283 Grade A Chemical Composition

In asme sa283 grade a structural steel specifications, low carbon ensures easy welding, with manganese adding basic strength.

Composition table:

Element

Composition (%)

Carbon (C)

0.24 max

Manganese (Mn)

0.90 max

Phosphorus (P)

0.035 max

Sulfur (S)

0.040 max

Copper (Cu)

0.20 min (if copper-bearing)



Mechanical Properties

Per sa283 gr a carbon steel plate dimensions, it offers low tensile for simple structures.

Properties table:

Property

Value

Tensile Strength

45-60 ksi (310-415 MPa)

Yield Strength

24 ksi (165 MPa) min

Elongation (in 50mm)

30% min



Dimensions

Thickness: 6-50mm; Width: 1500-3200mm; Length: up to 12000mm. Custom cuts available.



Pricing

As of October 07, 2025, current pricing for asme sa283 grade a boiler plates ranges $450-900/ton, averaging $500-700 in Asia, $800-900 in Europe/NA. India: ₹65-100/kg.
