A662GrC,A662 Grade C,A662 Gr.C STEEL PLATE supplier



Gangsteel produced Super thickness steel plate of A662GrC,A662 Grade C,A662 Gr.C STEEL PLATE

ASTM A662 standard specification for pressure vessel plates, carbon-manganese-silicon steel, for moderate and lower temperature service

ASTM A662 plates over 40mm in thickness shall be normalized. Plates of Grades B and C, 40 mm and under in thickness, are normally supplied in the as-rolled condition. The plates may be ordered normalized or stress relieved, or both.



   ASTM A662 Grade C Chemical Composition

Grade

The Element Max (%)

C

Si

Mn

P

S

Al

N

A662 Grade C

0,24

0.13-0.55

0.92-1.72

0,035

0,035





Nb

V

Ti

Cu

Cr

Ni

Mo















Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%





Grade



 ASTM A662 Grade C Mechanical Property

Thickness

Yield

Tensile

Elongation

A662 Grade C

mm

Min Mpa

Mpa

Min  %

6-50

295

480-620

22%

50-200

295

480-620

18%





ASTM A662 GR.C Equivalent Grades Table

Below is a table showing the equivalent grades for ASTM A662 (Grades A, B, and C) with reference to international standards such as European (EN) and Japanese (JIS) standards.



ASTM A662 Grade

European Standard (EN)

Japanese Standard (JIS)

Other Equivalent Standards

Remarks

A662 Grade A

P275NL1 (1.0488)

-

-

Non-alloy low-temperature quality steel for pressure vessels

A662 Grade B

-

-

-

No clear equivalent; match based on chemical composition and mechanical properties

A662 Grade C

P355NH (1.0565)

-

-

Non-alloy high-temperature quality steel for higher strength requirements



Notes:

  1. Chemical Composition Differences: ASTM A662 grades differ primarily in manganese (Mn) content, which increases from Grade A to C, enhancing yield and tensile strength. For example, Grade C has a manganese range of 0.79-1.62%.
  2. Application: ASTM A662 steel plates are used for welded pressure vessels, suitable for moderate to low temperatures and specific pressure conditions.
  3. Equivalent Standard Limitations: Some equivalents may have slight differences in chemical composition or mechanical properties. Verification through material testing is recommended for specific applications.
  4. Data Sources: The equivalents are based on cross-references from steelnumber.com and equivalentmaterials.com.
  5. Missing Information: No clear international equivalent was found for Grade B; further matching may be needed based on project requirements.







If you need quotation for steel plates in pressure vessel steel plate, please contact us by email
