316Ti Stainless Steel Pipe & Tube: Seamless Stock Ready
Published: November 8, 2025 | Updated: November 8, 2025By Gangsteel Engineering Team – 25+ Years in Stainless Steel Export Excellence
In the specialized market for corrosion-resistant piping solutions, 316Ti stainless steel pipes and tubes offer exceptional performance in high-temperature and acidic environments, thanks to titanium stabilization that prevents intergranular corrosion.
As a premier producer and exporter based in China, Gangsteel maintains ready stock of seamless 316Ti pipes and tubes under standards like ASME SA312/SA213 for pipes/tubes, ASTM A312/A213 for general specs, EN 10216-5 for European norms, JIS G3459/G3463 for Japanese standards, and AISI 316Ti for American nomenclature.
If you're sourcing for a chemical processing line or marine system, our seamless stock in various sizes ensures quick availability with full compliance. This guide details specs, properties, and our inventory for 316Ti (UNS S31635, EN 1.4571), based on industry standards and our mill expertise.
From our warehouses, we've shipped seamless 316Ti pipes on demand: In Q3 2025, a U.S. pharmaceutical client received our 50mm OD stock in 10 days, enabling sterile line installation without delays, as per their feedback. Often sourced under ASTM A240 /A240M for base material or ASME SA240/SA240M for compliance, our pipes with density 8.00 g/cm³ and PREN 23-28 deliver durability. With sizes from 6mm OD (for precision tubes) to 610mm OD (for heavy pipes), Gangsteel's seamless stock meets diverse needs. Let's explore the details, from composition to sourcing, to see how our inventory can support your project.
Summary
Gangsteel is your reliable supplier for seamless 316Ti stainless steel pipes and tubes (UNS S31635, EN 1.4571, JIS SUS316Ti, AISI 316Ti), available in OD 6-610mm, wall 1-50mm, lengths up to 18m, with titanium stabilization for high-temp IGC resistance. Mechanical properties include tensile 515 MPa min, yield 205 MPa min, and hardness 95 HRB max, ideal for chemical and marine apps. Density 8.00 g/cm³ supports efficient designs. Under specs like ASME SA312/SA213 316Ti and ASTM A312/A213 316Ti, pricing is $3,500-5,500/ton FOB in 2025. Equivalents like DIN 1.4571 in stock with dual certs. Choose Gangsteel for mill-direct quality, fast delivery (7-30 days), and competitive pricing.
Chemical Composition: Full Breakdown for Stability
316Ti's full chemical composition is optimized with titanium to bind carbon and prevent sensitization, ensuring pipe and tube integrity in high-heat corrosives.
Full Chemical Composition (per ASTM A240/A312, ASME SA240/SA312, EN 1.4571, JIS SUS316Ti, AISI 316Ti; % by weight, heat analysis):
|
Element |
% Minimum |
% Maximum |
Role in Pipe & Tube Properties |
|---|---|---|---|
|
Carbon (C) |
- |
0.08 |
Controlled low to minimize carbide formation; titanium stabilizes for IGC resistance in welded pipes. |
|
Manganese (Mn) |
- |
2.00 |
Deoxidizer; enhances strength and formability in tube drawing. |
|
Silicon (Si) |
- |
0.75 |
Improves oxidation resistance; aids seamless tube extrusion. |
|
Phosphorus (P) |
- |
0.045 |
Impurity limited to maintain ductility in high-pressure pipes. |
|
Sulfur (S) |
- |
0.030 |
Kept low for weldability and corrosion in tube joints. |
|
Chromium (Cr) |
16.00 |
18.00 |
Provides passivation; core for corrosion resistance in marine tubes. |
|
Molybdenum (Mo) |
2.00 |
3.00 |
Enhances pitting resistance; key for chloride-exposed pipes. |
|
Nickel (Ni) |
10.00 |
14.00 |
Stabilizes austenite; boosts general durability in high-temp tubes. |
|
Titanium (Ti) |
5x(C+N) |
0.70 |
Stabilizer against sensitization; essential for high-temp pipe apps. |
|
Nitrogen (N) |
- |
0.10 |
Strengthens matrix; included in Ti calc for specs. |
|
Iron (Fe) |
Balance |
- |
Base element; consistent across standards. |
This full composition ensures compliance, with titanium (typically 0.4-0.7%) preventing Cr depletion. Gangsteel's melts meet tight specs for seamless quality.
Mechanical Properties: Full Data for Structural Integrity
316Ti's mechanical properties are robust, with full data supporting its use in high-temp piping.
Full Mechanical Properties (annealed condition, per ASTM A312/A213, ASME SA312/SA213, EN 10216-5, JIS G3459/G3463, AISI 316Ti):
|
Property |
Minimum Value |
Typical Range |
Notes on Pipe & Tube Specs |
|---|---|---|---|
|
Tensile Strength (MPa) |
515 |
550-700 |
High for pressure ratings; stable at heat. |
|
Yield Strength (0.2% Offset, MPa) |
205 |
220-300 |
Ensures integrity in seamless tubes under load. |
|
Elongation (%) |
35 (longitudinal) |
40-55 |
Good for tube bending without cracks. |
|
Reduction of Area (%) |
Not specified |
50-60 |
Indicates toughness in tension for pipes. |
|
Hardness (HRB max) |
95 |
80-90 |
Low for easy threading in fittings. |
|
Brinell Hardness (HB max) |
217 |
160-190 |
Converted; meets EN specs for durability. |
|
Charpy V-Notch Impact (J at RT) |
Not required |
100+ |
High; maintains in cold-formed tubes. |
|
Flattening Test |
No cracks |
- |
Per A312 specs for tube quality. |
|
Hydrostatic Test Pressure |
Per size |
- |
ASME SA312 requires for leak-proof. |
These full specs ensure 316Ti pipes/tubes perform in high-temp, with yield retention >70% at 815°C. Gangsteel's seamless stock exceeds mins, with elongation up to 55%.
Physical Properties: Supporting Pipe & Tube Design
Physical data for 316Ti is consistent, aiding flow and pressure calcs.
|
Property |
Value |
Notes on Pipe & Tube |
|---|---|---|
|
Density (g/cm³) |
8.00 |
For weight/volume in piping. |
|
Melting Range (°C) |
1370-1400 |
High for thermal pipes. |
|
Thermal Conductivity (W/m·K at 100°C) |
14.6 |
Good for heat transfer tubes. |
|
Specific Heat (J/kg·K) |
500 |
Efficient in cycling. |
|
Thermal Expansion (10^-6 /°C, 20-100°C) |
16.5 |
Low for joint stability. |
|
Modulus (GPa) |
193 |
High for pressure resistance. |
Density 8.00 g/cm³ enables calcs like 50mm OD x 5mm wall tube ~9.4 kg/m.
For UNS stainless steel plates, our pipes complement.
Corrosion Resistance: Pipe & Tube Focus
PREN 23-28 resists pitting; Ti prevents IGC at 425-815°C for seamless integrity.
Gangsteel's pipes show <0.1 mm/year in acids.
Weldability and Fabrication: Seamless Advantages
Seamless stock welds without annealing; machinability 60% of steel.
Our A240 GR 316Ti tubes fabricate easily.
Applications: High-Pressure and Temp
Seamless 316Ti pipes/tubes suit chemical lines (IGC resistance), marine (pitting defense), power (thermal stability).
In Gangsteel's supply, 100mm pipes for boilers.
Equivalents: Global Options
Equivalents: EN 1.4571, JIS SUS316Ti—seamless available.
Sourcing from Gangsteel: Ready Stock
Stock: OD 6-610mm, wall 1-50mm, $3,500-5,500/ton FOB. Custom; lead 7-30 days.
FAQ: 316Ti Stainless Steel Pipe & Tube: Seamless Stock Ready Questions Answered
Q: What sizes are available in seamless 316Ti stainless steel pipes from Gangsteel?
A: Gangsteel stocks seamless 316Ti pipes in OD 6-610mm, wall 1-50mm, lengths up to 18m, ASME SA312 316Ti compliant.
Q: What is the pricing for seamless 316Ti stainless steel tubes in 2025?
A: Pricing for seamless 316Ti tubes is $3,500-5,500 per ton FOB ($3.5-5.5 per kg) in 2025; smaller OD higher, bulk discounts available.
Q: Does Gangsteel supply ASME SA312 316Ti certified seamless pipes?
A: Yes, our seamless 316Ti pipes are ASME SA312 and ASTM A312 certified, with full traceability.
Q: What applications suit seamless 316Ti stainless steel pipes and tubes?
A: Seamless 316Ti pipes suit chemical lines (acid resistance), marine tubes (pitting defense), power piping (high-temp durability).
Q: What is the density of 316Ti stainless steel pipes?
A: Density is 8.00 g/cm³ for 316Ti pipes, consistent for calcs (e.g., 50mm OD x 5mm wall ~9.4 kg/m).
Q: How does Gangsteel ensure quality in seamless 316Ti pipes?
A: Through ISO-certified production, full certs (3.1/3.2), and tests like hydro/UT for seamless integrity.
Q: Can Gangsteel supply equivalents to 316Ti in seamless pipes?
A: Yes, equivalents like EN 1.4571 in seamless pipes with dual certs.
