Published: November 8, 2025 | Updated: November 8, 2025By Gangsteel Engineering Team – 25+ Years in Stainless Steel Export Excellence
In the specialized field of stainless steel welding, 316Ti wire and rod provide a reliable solution for applications requiring high corrosion resistance and stability in elevated temperatures, thanks to titanium stabilization that prevents intergranular attacks during welding.
As a premier producer and exporter based in China, Gangsteel offers extensive stock of 316Ti wire and rod under standards like ASME SA240/SA240M for pressure compliance and ASTM A240/A240M for general specs, serving industries such as petrochemical, pharmaceutical, and marine.
If you're selecting filler materials for a chemical piping weld or high-temp joint, understanding 316Ti's wire and rod options is essential. This guide covers composition, properties, welding tips, and applications, based on industry standards and our mill expertise.
From our production, we've seen 316Ti wire perform: In a 2024 European pharma line, our ER316Ti rod ensured joints resisted acidic steam at 150°C without leaks, as per client tests. Often used as equivalents to EN 1.4571 or JIS SUS316Ti wire, 316Ti's density 8.00 g/cm³ and PREN 23-28 make it durable. Gangsteel's stock includes diameters 0.8-5.0mm for wire and 10-500mm for rod, priced at $4-6 per kg FOB. Let's explore the details, from composition to sourcing, to see how our stock can meet your welding needs.
316Ti stainless steel wire and rod (UNS S31635, EN 1.4571, JIS SUS316Ti, AISI 316Ti) are ideal for welding in high-temp corrosives, with titanium preventing IGC and molybdenum boosting pitting resistance (PREN 23-28). Composition includes C 0.08 max, Ti 0.7 max; mechanicals like tensile 515 MPa min, yield 205 MPa min. Density 8.00 g/cm³ supports efficient use. Under ASME SA240 316Ti and ASTM A240 316Ti specs, they're suited for chemical and marine welds. Gangsteel stocks wire (0.8-5.0mm) and rod (10-500mm) at $4-6 per kg FOB 2025, with fast global delivery. Equivalents like DIN 1.4571 available. Choose Gangsteel for mill-direct quality and custom lengths.
316Ti's full composition is designed for weldability, with titanium binding carbon to avoid sensitization in the HAZ.
Full Chemical Composition (per ASTM A240, ASME SA240, EN 1.4571, JIS SUS316Ti, AISI 316Ti; % by weight, heat analysis):
|
Element |
% Minimum |
% Maximum |
Role in Welding |
|---|---|---|---|
|
Carbon (C) |
- |
0.08 |
Low to minimize carbides; Ti binds for no IGC in welds. |
|
Manganese (Mn) |
- |
2.00 |
Deoxidizer; aids filler flow without corrosion impact. |
|
Silicon (Si) |
- |
0.75 |
Improves arc stability; enhances oxidation resistance in heat. |
|
Phosphorus (P) |
- |
0.045 |
Limited for ductility in welded joints. |
|
Sulfur (S) |
- |
0.030 |
Low for clean welds; avoids hot cracking. |
|
Chromium (Cr) |
16.00 |
18.00 |
Provides passivation; maintains corrosion in HAZ. |
|
Molybdenum (Mo) |
2.00 |
3.00 |
Boosts pitting resistance in welded areas. |
|
Nickel (Ni) |
10.00 |
14.00 |
Stabilizes austenite for tough welds. |
|
Titanium (Ti) |
5x(C+N) |
0.70 |
Stabilizes against sensitization; key for high-temp welds. |
|
Nitrogen (N) |
- |
0.10 |
Strengthens welds; included in Ti calc. |
|
Iron (Fe) |
Balance |
- |
Base for stable arc and filler. |
This full composition ensures no sensitization, with Gangsteel's wire/rod meeting tight specs for clean welding.
316Ti's mechanical data ensures strong, durable welds.
Full Mechanical Properties (annealed, per ASTM A240, ASME SA240, EN 1.4571, JIS SUS316Ti, AISI 316Ti):
|
Property |
Minimum Value |
Typical Range |
Notes on Welding |
|---|---|---|---|
|
Tensile Strength (MPa) |
515 |
550-700 |
Retains in welds; no drop post-PWHT. |
|
Yield Strength (0.2% Offset, MPa) |
205 |
220-300 |
Ensures joint strength; Ti stabilizes HAZ. |
|
Elongation (%) |
40 |
45-55 |
High for weld ductility without cracks. |
|
Reduction of Area (%) |
Not specified |
50-60 |
Indicates toughness in welded tension. |
|
Hardness (HRB max) |
95 |
80-90 |
Low for easy rod machining pre-weld. |
|
Brinell Hardness (HB max) |
217 |
160-190 |
Converted; meets specs for weld prep. |
|
Charpy V-Notch Impact (J at RT) |
Not required |
100+ |
Maintains in welds; Ti prevents brittleness. |
Gangsteel's wire/rod achieves elongation up to 55%, ideal for welding.
Density 8.00 g/cm³; thermal conductivity 14.6 W/m·K—supports arc stability.
For UNS stainless steel plates, our wire complements.
PREN 23-28 resists pitting in welds; Ti prevents IGC in HAZ.
Gangsteel's rod shows <0.1 mm/year in acids post-weld.
316Ti wire/rod (ER316Ti) welds with low heat input; no annealing needed.
Tips: Argon shield, 100-150A for 2.4mm wire; PWHT optional at 1050°C.
Our A240 GR 316Ti rod ensures clean joints.
316Ti wire/rod for chemical lines (IGC resistance), marine welds (pitting defense), power joints (thermal stability).
In Gangsteel's supply, 316Ti wire for boilers.
Equivalents: EN 1.4571, JIS SUS316Ti—wire/rod available.
Stock: Wire 0.8-5.0mm, rod 10-500mm, $4-6 per kg FOB. Custom; lead 7-30 days.
Q: What is the chemical composition of 316Ti stainless steel wire and rod?
A: Full composition: C 0.08 max, Mn 2.00 max, Si 0.75 max, P 0.045 max, S 0.030 max, Cr 16.00-18.00, Mo 2.00-3.00, Ni 10.00-14.00, Ti 5x(C+N) min to 0.70 max, N 0.10 max, Fe balance. Ti stabilizes for weld integrity.
Q: What are the mechanical properties of 316Ti stainless steel wire and rod?
A: Full properties: Tensile 515 MPa min, yield 205 MPa min, elongation 40% min, reduction of area 50-60%, hardness 95 HRB max (217 HB max), impact 100+ J at RT. These ensure strong, durable welds.
Q: What filler wire is recommended for welding 316Ti?
A: ER316L or E316LT filler wire for 316Ti; matches composition for corrosion resistance without carbide issues.
Q: Is 316Ti stainless steel wire suitable for high-temperature welding?
A: Yes, 316Ti wire resists IGC at high temps; use low heat input to maintain properties.
Q: What sizes are available for 316Ti stainless steel rod from Gangsteel?
A: Gangsteel stocks 316Ti rod in 10-500mm diameters, custom lengths up to 12m.
Q: How does Gangsteel ensure quality in 316Ti wire and rod?
A: Through ISO-certified production, full certs (3.1/3.2), and tests like tensile/impact for welding quality.
Q: Can Gangsteel supply equivalents to 316Ti for welding wire?
A: Yes, equivalents like EN 1.4571 wire with dual certs for welding needs.
