Gangsteel – China’s Largest Mill-Direct Supplier & Exporter of EN 10025-4 S420M High Strength Steel Plates

Gangsteel maintains the largest permanent stock of EN 10025-4 S420M high strength steel plates in Asia – over 4,000 tons always ready in thickness 6–200 mm, width 1500–4200 mm, length up to 18 meters. All plates are genuine TMCP (thermomechanical controlled process) produced by top Chinese mills (HBIS, Shougang, Nanjing Steel) with full European approvals (PED 2014/68/EU, CPR 305/2011).

We supply with original EN 10204-3.1/3.2 certificates and third-party inspection (DNV-GL, ABS, LR, BV, CCS, KR, TÜV, SGS). Z25/Z35 through-thickness quality in stock, 100 % ultrasonic testing EN 10160 S2/E2 standard.

Immediate delivery worldwide in 3–7 days. Full processing services: plasma/oxy cutting, beveling, drilling, rolling, priming.

Explore our complete en 10025 4 High Strength Structural Steel series, including the popular low-temperature grade en 10025 4 s420ml steel plate, the widely used en 10025 4 s355ml steel plate, higher-strength en 10025 4 s460m steel plate, top-end en 10025 4 s460ml steel plate, entry-level en 10025 4 s275ml steel plate and en 10025 4 s275m steel plate, as well as the standard-temperature en 10025 4 s355m steel plate and the exact grade en 10025 4 s420m steel plate.

What is EN 10025-4 S420M High Strength Steel Plate?

EN 10025-4 S420M is a thermomechanically rolled (TMCP) weldable fine-grain structural steel with:

• Minimum yield strength 420 MPa
• Excellent toughness ≥ 40 J at –20 °C (longitudinal)
• Very low CEV ≤ 0.48 → outstanding weldability (no preheat up to 80 mm)
• Fine grain structure (ASTM 8–11)

The designation “S420M” means:

• S= structural steel
• 420= minimum yield strength 420 MPa (transverse, thickness ≤ 16 mm)
• M= thermomechanical rolling (TMCP delivery condition)

S420M is the mid-range high-strength grade in the EN 10025-4 family, perfectly balancing cost, strength, and weldability when service temperature is above –20 °C.

Chemical Composition – Ladle Analysis (max % unless noted)

Typical Gangsteel actual values: C 0.09–0.13 %, CEV 0.40–0.46 → excellent weldability without preheating up to 80 mm thickness.

Mechanical Properties – Full Thickness Range up to 200 mm (transverse values)

*Gangsteel guarantees higher values in thick plates by agreement.

Hardness: 150–200 HBW Density: 7.85 g/cm³

Available Specifications & Testing

• Thickness: 6–200 mm (20–120 mm most popular in stock)
• Width: 1500–4200 mm
• Length: up to 18 000 mm
• Z-quality: Z25 standard, Z35 large stock
• NDT: 100 % ultrasonic testing EN 10160 S2/E2 (S3/E3 optional)
• Surface: shot-blasted + primer or mill finish
• Certification: EN 10204-3.1/3.2, PED, CPR, all major class approvals

Applications of EN 10025-4 S420M Plates

S420M is widely used when high strength is required:

• Mobile and crawler cranes
• Heavy lifting equipment
• Offshore crane pedestals
• Wind turbine towers (onshore)
• Bridge girders and trusses
• Mining equipment

When the temperature drops below –20 °C, the low-temperature version S420ML is required.

Why Choose Gangsteel for S420M Plates

• Largest S420M stock in Asia (4,000+ tons ready)
• Factory-direct price – 60–120 USD/ton lower than traders
• Full processing capability (cutting, beveling, drilling, rolling, priming)
• Z35 quality always in stock
• Immediate delivery worldwide
• Exported to 90+ countries with perfect documentation
• One-stop service – stock → processing → shipping

FAQ – Quick Answers

Q1: S420M vs S420ML difference?A: Only impact test temperature. S420ML = –50 °C (≥27 J), S420M = –20 °C (≥40 J). Strength, chemistry, weldability identical.

Q2: Preheating required?A: No preheat up to 80 mm thickness. >80 mm: 75–100 °C max.

Q3: Z35 availability?A: Yes – very large stock of S420M + Z35 ready for immediate delivery.

Q4: Density and hardness?A: Density 7.85 g/cm³, hardness 150–200 HBW.

Q5: NDT standard?A: 100 % UT EN 10160 S2/E2 included. S3/E3, MT, PT on request.

Q6: Maximum thickness?A: Up to 200 mm with full properties and certification.

Q7: Delivery time?A: Stock material 3–7 days worldwide.
