316Ti Stainless Steel Plate: 1-200mm Thickness Available
Published: November 8, 2025 | Updated: November 8, 2025By Gangsteel Engineering Team – 25+ Years in Stainless Steel Export Excellence
In the specialized market for high-performance stainless steel plates, 316Ti offers unmatched resistance to intergranular corrosion in high-temperature and acidic settings, making it a top choice for demanding projects.
As a premier producer and exporter based in China, Gangsteel maintains extensive stock of ASME SA240 316Ti and ASTM A240 316Ti plates in thicknesses from 1mm to 200mm, serving industries like petrochemical, pharmaceutical, marine, and power generation.
If you're sourcing plates for a chemical reactor or exhaust system, our 1-200mm range ensures availability for everything from thin liners to heavy structural components. This guide details our stock, properties, and applications, based on industry standards and our mill expertise.
From our warehouses, we've shipped 316Ti plates on short notice: In Q3 2025, a European marine firm received our 50mm thick stock in 10 days, enabling quick assembly with no delays, as per their feedback. Often specified under ASTM A240 /A240M for general use or ASME SA240/SA240M for pressure compliance, our plates with density 8.00 g/cm³ and PREN 23-28 deliver durability. With thicknesses from 1mm (for cladding) to 200mm (for hubs), Gangsteel's stock meets diverse needs. Let's explore the details, from composition to sourcing, to see how our inventory can support your project.
Summary
Gangsteel's 316Ti stainless steel plates (UNS S31635, EN 1.4571, JIS SUS316Ti, AISI 316Ti) are available in 1-200mm thicknesses, offering titanium-stabilized corrosion resistance for high-temp apps. With tensile 515 MPa min, yield 205 MPa min, and hardness 95 HRB max, they're ideal for chemical and marine use. Density 8.00 g/cm³ supports efficient designs. Under ASME SA240 316Ti and ASTM A240 316Ti specs, prices are $3,200-3,800/ton FOB, with fast global delivery. Equivalents like DIN 1.4571 in stock with dual certs. Choose Gangsteel for mill-direct quality and 1-200mm ready stock.
Chemical Composition: Stabilized for Performance
316Ti's composition includes titanium to prevent carbide precipitation, ensuring reliability in high-temp corrosives.
Composition (ASTM A240):
|
Element |
% Range |
|---|---|
|
Cr |
16-18 |
|
Mo |
2-3 |
|
Ni |
10-14 |
|
Ti |
0.7 max |
|
C |
0.08 max |
Full certs with our stock.
Properties: Robust Across Thicknesses
Our 1-200mm plates meet specs with consistent properties.
|
Property |
Value |
|---|---|
|
Tensile (MPa) |
515 min |
|
Yield (MPa) |
205 min |
|
Elongation (%) |
40 min |
|
Hardness (HRB) |
95 max |
Thicker plates (100-200mm) retain yield for structural use.
Gangsteel's SA240 Type 316Ti stock exceeds mins.
Physical Properties: Consistent for Design
Density 8.00 g/cm³ across 1-200mm; thermal conductivity 14.6 W/m·K.
This supports calcs: 10mm plate 80 kg/m²; 200mm 1,600 kg/m².
For UNS stainless steel plates, our stock is ready.
Corrosion Resistance: High-Temp Focus
PREN 23-28 resists pitting; Ti prevents IGC at 425-815°C.
Gangsteel's stock shows <0.1 mm/year in acids.
Weldability and Fabrication: Easy Across Range
Welds without annealing; machinability 60% of steel.
Our 1-200mm stock cuts easily; A240 GR 316Ti for custom.
Applications: Versatile for Thicknesses
- 1-20mm: Cladding (corrosion).
- 21-100mm: Reactors (strength).
- 101-200mm: Hubs (load).
In Gangsteel's supply, 150mm plates for boilers.
Equivalents: Global Options
Equivalents: EN 1.4571, JIS SUS316Ti—stocked with dual certs.
Sourcing from Gangsteel: 1-200mm Stock Ready
Stock: 1-200mm thick, $3,200-3,800/ton FOB. MOQ 1 ton; lead 7-30 days. Certs included.
FAQ: 316Ti Stainless Steel Plate: 1-200mm Thickness Available Questions Answered
Q: What thicknesses are available in 316Ti stainless steel plates from Gangsteel?
A: Gangsteel stocks 316Ti plates from 1mm (thin sheets for cladding) to 200mm (heavy for hubs), all ASME SA240 316Ti compliant.
Q: What is the price for 316Ti stainless steel plates in 1-200mm range?
A: Prices range $3,200-3,800/ton FOB for 1-200mm 316Ti plates; thinner lower, thicker higher with certs.
Q: Does Gangsteel offer ASME SA240 316Ti plates in 1-200mm?
A: Yes, our full 1-200mm stock is ASME SA240 and ASTM A240 certified, with custom cuts available.
Q: What applications suit 1-200mm 316Ti stainless steel plates?
A: Thin 1-50mm for exchangers (corrosion resistance), 51-200mm for vessels (strength); high-temp durability across range.
Q: What is the density of 316Ti stainless steel plates?
A: Density is 8.00 g/cm³ for 316Ti plates, consistent 1-200mm for weight calcs (e.g., 80 kg/m² at 10mm).
Q: How does Gangsteel ensure quality in 1-200mm 316Ti plates?
A: Through ISO-certified production, full certs (3.1/3.2), and tests like UT for thick stock.
Q: Can I get equivalents to 316Ti in 1-200mm thicknesses from Gangsteel?
A: Yes, equivalents like EN 1.4571 stocked in 1-200mm with dual certs for global use.
