Gangsteel produces 430 stainless steel with consistent thermal conductivity that fully complies with the leading international standards. We can manufacture to any of the following major specifications to meet your exact project requirements:
430 stainless steel (AISI 430 / UNS S43000) is a ferritic grade that offers significantly higher thermal conductivity than austenitic grades such as 304 or 316. This property makes it particularly suitable for heat exchangers, appliances, and thermal management components.
Thermal Conductivity Values (Annealed Condition):
|
Temperature (°C) |
Thermal Conductivity (W/m·K) |
|---|---|
|
20–100 |
26.0 – 26.5 |
|
100–200 |
26.5 – 27.0 |
|
200–300 |
27.0 – 27.5 |
|
300–400 |
27.5 – 28.0 |
|
400–500 |
28.0 – 28.5 |
These values are typical and consistent across all major standards (ASTM A240, JIS G4305, EN 10088-2, GB/T 3280, etc.). The thermal conductivity of 430 is approximately 60–70% higher than austenitic stainless steels (e.g., 304 is ~16 W/m·K at room temperature), which reduces thermal gradients and improves heat dissipation.
For full product details on 430 stainless steel sheet or coil with these thermal properties, please see our:
Gangsteel guarantees every batch meets or exceeds the physical property requirements of the chosen standard, with full mill test certificates provided. If you need thermal conductivity data at specific temperatures, for cold-worked tempers, or custom testing, contact our technical team for details.
