EN 10025-4 S355M Weldable Fine Grain Plate Supplier

EN 10025-4 S355M Weldable Fine Grain Plate Supplier

Gangsteel – China's Leading Mill-Direct Supplier & Exporter of EN 10025-4 S355M Weldable Fine Grain Plates

Gangsteel is the most reliable source for EN 10025-4 S355M weldable fine grain plates, with the largest permanent stock in Asia – over 4,000 tons always ready in thickness 6–200 mm, width 1500–4200 mm, length up to 18 meters. All plates are genuine TMCP (thermomechanical controlled process) produced by top Chinese mills (HBIS, Shougang, Nanjing Steel) with full European approvals (PED 2014/68/EU, CPR 305/2011).

We supply with original EN 10204-3.1/3.2 certificates and third-party inspection (DNV-GL, ABS, LR, BV, CCS, KR, TÜV, SGS). Z25/Z35 through-thickness quality in stock, 100 % ultrasonic testing EN 10160 S2/E2 standard.

Immediate delivery worldwide in 3–7 days. Full processing services: plasma/oxy cutting, beveling, drilling, rolling, priming.

Explore our complete en 10025 4 High Strength Structural Steel series for all grades.

What is EN 10025-4 S355M Weldable Fine Grain Plate?

EN 10025-4 S355M is a thermomechanically rolled (TMCP) weldable fine grain structural steel with:

• Minimum yield strength 355 MPa
• Impact toughness ≥ 40 J at –20 °C (longitudinal)
• Very low CEV ≤ 0.39 → outstanding weldability (no preheat up to 80 mm)
• Fine grain structure (ASTM 8–11) from controlled microalloying (Nb, V, Ti)

The combination of weldable (low CEV, clean steel) and fine grain (microalloying + TMCP) makes S355M the perfect balance between high strength and easy fabrication when service temperature is above –20 °C.

S355M is the standard-temperature version of the most popular grade in the EN 10025-4 family. It is the direct TMCP alternative to normalized S355N (EN 10025-3) and the sister grade to the low-temperature bestseller S355ML (–50 °C).

Chemical Composition – Ladle Analysis (max % unless noted)

Typical Gangsteel actual values: C 0.09–0.12 %, CEV 0.34–0.37 → excellent weldability without preheating up to 80 mm thickness.

Mechanical Properties – Full Thickness Range up to 200 mm (transverse values)

*Gangsteel guarantees 295 MPa up to 180 mm, 285 MPa to 200 mm.

Hardness: 140–180 HBW Density: 7.85 g/cm³

Available Specifications & Testing

• Thickness: 6–200 mm (20–120 mm most popular in stock)
• Width: 1500–4200 mm
• Length: up to 18 000 mm
• Z-quality: Z25 standard, Z35 large stock
• NDT: 100 % ultrasonic testing EN 10160 S2/E2 (S3/E3 optional)
• Surface: shot-blasted + primer or mill finish
• Certification: EN 10204-3.1/3.2, PED, CPR, all major class approvals

Applications of EN 10025-4 S355M Weldable Fine Grain Plates

S355M is widely used when the service temperature is above –20 °C:

• General structural engineering
• Bridges and highway structures
• Onshore wind turbine towers
• Heavy machinery bases
• Crane booms and lifting equipment
• Shipbuilding and marine structures (non-Arctic)

When the temperature drops below –20 °C, the low-temperature version S355ML is required.

Why Choose Gangsteel for S355M Weldable Fine Grain Plates

• Largest S355M stock in Asia (4,000+ tons ready)
• Factory-direct price – 60–120 USD/ton lower than traders
• Full processing capability (cutting, beveling, drilling, rolling, priming)
• Z35 quality always in stock
• Immediate delivery worldwide
• Exported to 90+ countries with perfect documentation
• One-stop service – stock → processing → shipping

FAQ – Detailed Answers

Q1: What is the difference between S355M and S355ML?

A: The only difference is the impact test temperature. S355M is tested at –20 °C with minimum 40 J (longitudinal), while S355ML is tested at –50 °C with minimum 27 J. Yield strength, tensile strength, elongation, chemical composition, and weldability are exactly the same. Choose S355M when service temperature is above –20 °C; choose S355ML when below –20 °C.

Q2: Is preheating required when welding S355M?

A: No preheating is required up to 80 mm thickness thanks to the very low CEV (typically 0.34–0.37 actual). For thicknesses over 80 mm or highly restrained joints, a modest preheat of 75–100 °C is sufficient. This is a major advantage over many other structural steels.

Q3: Do you have Z35 quality in stock for S355M?

A: Yes – we keep very large stock of S355M + Z35 (reduction of area ≥35 % per EN 10164 Class 3), especially in 20–120 mm thickness, ready for immediate delivery. Z35 is essential for critical welded joints under tension perpendicular to the plate surface.

Q4: What is the density and hardness of S355M?

A: Density is 7.85 g/cm³ (7850 kg/m³), hardness is 140–180 HBW (typical 150–170 HBW in our stock). These values are consistent across the entire thickness range.

Q5: What NDT do you provide as standard?

A: 100 % ultrasonic testing to EN 10160 S2/E2 is included with every plate. We can upgrade to S3/E3, magnetic particle (MT), or penetrant testing (PT) on request at no extra charge for reasonable quantities.

Q6: What is the maximum thickness you can supply for S355M?

A: Up to 200 mm with full properties and certification. We guarantee minimum yield of 295 MPa up to 180 mm and 285 MPa to 200 mm – significantly better than the standard requirement.

Q7: How fast can you deliver to Europe or USA?

A: From ready stock: 7–12 days to Rotterdam, Antwerp, Houston, conceptualized or Los Angeles. We have regular consolidation containers and can offer air freight for urgent small quantities (<10 tons) in 48–72 hours.

Contact Gangsteel Today

Need EN 10025-4 S355M weldable fine grain plates? Contact us now for best price and fastest delivery.

Email: admin@gangsteel.com WhatsApp/WeChat/Mobile: +86 135 9887 9167 Website: https://gangsteel.net/

Gangsteel – Real Factory. Real Stock. Real Fast Delivery.
