Gangsteel – China's Leading Mill-Direct Supplier & Exporter of S355M Meaning EN 10025-4 Structural Grade Plates
Gangsteel is the definitive supplier for S355M meaning EN 10025-4 structural grade plates, with the largest permanent stock in Asia – over 4,000 tons always ready in thickness 6–200 mm, width 1500–4200 mm, length up to 18 meters. All plates are genuine TMCP (thermomechanical controlled process) produced by top Chinese mills (HBIS, Shougang, Nanjing Steel) with full European approvals (PED 2014/68/EU, CPR 305/2011).
We supply with original EN 10204-3.1/3.2 certificates and third-party inspection (DNV-GL, ABS, LR, BV, CCS, KR, TÜV, SGS). Z25/Z35 through-thickness quality in stock, 100 % ultrasonic testing EN 10160 S2/E2 standard.
Immediate delivery worldwide in 3–7 days. Full processing services: plasma/oxy cutting, beveling, drilling, rolling, priming.
Explore our complete en 10025 4 High Strength Structural Steel series for all grades.
The designation S355M in EN 10025-4:2004 (current version 2019) is a precise technical code that tells engineers everything they need to know about the material in just five characters.
Here is the complete breakdown of S355M meaning:
|
Character |
Meaning |
Explanation |
|---|---|---|
|
S |
Structural steel |
Intended for load-bearing welded structures (bridges, buildings, offshore, cranes, etc.) |
|
355 |
Minimum yield strength 355 MPa |
Measured transverse to rolling direction for thickness ≤ 16 mm |
|
M |
Thermomechanical rolling (TMCP delivery) |
Controlled hot rolling + accelerated cooling – no separate normalizing heat treatment |
|
(no L) |
Standard low-temperature toughness |
Impact test at –20 °C with minimum 40 J (longitudinal) – compare with S355ML which is –50 °C |
S355M meaning in simple terms: A high-strength structural steel (355 MPa yield) delivered in thermomechanical rolled condition with normal low-temperature toughness (–20 °C).
It is the standard-temperature version of the very popular S355ML (–50 °C). When the lowest service temperature is above –20 °C, S355M is the cost-effective choice with identical strength and chemistry to S355ML.
For a detailed comparison with the low-temperature grade, see our article S355M vs S355ML EN 10025-4 Steel Plate Comparison Supplier.
|
Element |
C |
Si |
Mn |
P |
S |
Nb |
V |
Al min |
Ti |
Cr |
Ni |
Mo |
Cu |
N |
CEV max |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
S355M |
0.14 |
0.50 |
1.60 |
0.025 |
0.020 |
0.05 |
0.10 |
0.020 |
0.05 |
0.30 |
0.50 |
0.10 |
0.55 |
0.015 |
0.39 |
Typical Gangsteel actual values: C 0.09–0.12 %, CEV 0.34–0.37 → excellent weldability without preheating up to 80 mm thickness.
Full chemical data: S355M Chemical Composition EN 10025-4 Supplier
|
Thickness (mm) |
ReH min (MPa) |
Rm (MPa) |
A5 min (%) |
KV min (J) at –20 °C longitudinal |
|---|---|---|---|---|
|
≤ 16 |
355 |
470–630 |
22 |
40 |
|
>16 ≤ 40 |
345 |
470–630 |
22 |
40 |
|
>40 ≤ 63 |
335 |
470–630 |
22 |
40 |
|
>63 ≤ 80 |
325 |
470–630 |
22 |
40 |
|
>80 ≤ 100 |
315 |
470–630 |
22 |
40 |
|
>100 ≤ 120 |
305 |
450–610 |
22 |
40 |
|
>120 ≤ 150 |
295 |
450–610 |
22 |
40 |
|
>150 ≤ 200 |
285–295* |
450–610 |
22 |
40 |
*Gangsteel guarantees 295 MPa up to 180 mm, 285 MPa to 200 mm.
Hardness: 140–180 HBW Density: 7.85 g/cm³
Full mechanical tables: S355M Mechanical Properties EN 10025-4 Plate Supplier
S355M is widely used when the service temperature is above –20 °C:
When the temperature drops below –20 °C, the low-temperature version S355ML is required.
Q1: What does S355M mean exactly?
A: S = structural steel, 355 = minimum yield strength 355 MPa, M = thermomechanical rolling (TMCP delivery condition). No “L” means standard impact toughness at –20 °C (≥40 J). It is the standard-temperature version of the more common S355ML (–50 °C).
Q2: S355M vs S355ML difference?
A: Only the impact test temperature. S355M = –20 °C (≥40 J), S355ML = –50 °C (≥27 J). All other properties – yield, tensile, elongation, chemistry, weldability – are identical.
Q3: Is preheating required when welding S355M?
A: No preheating is required up to 80 mm thickness thanks to the very low CEV (typically 0.34–0.37 actual). For thicknesses over 80 mm or highly restrained joints, a modest preheat of 75–100 °C is sufficient.
Q4: Do you have Z35 quality in stock for S355M?
A: Yes – we keep very large stock of S355M + Z35 (reduction of area ≥35 % per EN 10164 Class 3), especially in 20–120 mm thickness, ready for immediate delivery.
Q5: What is the density and hardness of S355M?
A: Density is 7.85 g/cm³ (7850 kg/m³), hardness is 140–180 HBW (typical 150–170 HBW in our stock). These values are consistent across the entire thickness range.
Q6: What NDT do you provide as standard?
A: 100 % ultrasonic testing to EN 10160 S2/E2 is included with every plate. We can upgrade to S3/E3, magnetic particle (MT), or penetrant testing (PT) on request at no extra charge for reasonable quantities.
Q7: How fast can you deliver to Europe or USA?
A: From ready stock: 7–12 days to Rotterdam, Antwerp, Houston, or Los Angeles. We have regular consolidation containers and can offer air freight for urgent small quantities (<10 tons) in 48–72 hours.
Need S355M structural grade plates? Contact us now for best price and fastest delivery.
Email: admin@gangsteel.com WhatsApp/WeChat/Mobile: +86 135 9887 9167 Website: https://gangsteel.net/
Gangsteel – Real Factory. Real Stock. Real Fast Delivery.
