Gangsteel – China's Leading Mill-Direct Supplier & Exporter of EN10025-4 S355M High Strength Steel Plates
Gangsteel maintains the largest permanent stock of EN10025-4 S355M high strength steel plates in Asia — over 4,000 tons always ready in thickness 6–200 mm, width 1500–4200 mm, length up to 18 m. All plates are genuine TMCP (thermomechanical controlled process) produced by top Chinese mills (HBIS, Shougang, Nanjing Steel) with full European approvals (PED 2014/68/EU, CPR 305/2011).
We supply with original EN 10204-3.1/3.2 certificates and third-party inspection (DNV-GL, ABS, LR, BV, CCS, KR, TÜV, SGS). Z25/Z35 through-thickness quality in stock, 100 % ultrasonic testing EN 10160 S2/E2 standard.
Immediate delivery worldwide in 3–7 days. Full processing services: plasma/oxy cutting, beveling, drilling, rolling, priming.
Explore our complete en 10025 4 High Strength Structural Steel series.
EN10025-4 S355M is a thermomechanically rolled (TMCP) weldable fine-grain high strength structural steel with:
S355M is the standard-temperature version of the popular EN 10025-4 family. It is the direct TMCP alternative to normalized S355N (EN 10025-3) and the sister grade to the low-temperature bestseller en 10025 4 s355ml steel plate (–50 °C).
When service temperature stays above –20 °C, S355M offers the same high strength as S355ML at a lower price and with identical chemistry and weldability.
|
Element |
C |
Si |
Mn |
P |
S |
Nb |
V |
Al min |
Ti |
Cr |
Ni |
Mo |
Cu |
N |
CEV max |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
S355M |
0.14 |
0.50 |
1.60 |
0.025 |
0.020 |
0.05 |
0.10 |
0.020 |
0.05 |
0.30 |
0.50 |
0.10 |
0.55 |
0.015 |
0.39 |
Typical Gangsteel actual values: C 0.09–0.12 %, CEV 0.34–0.37 → excellent weldability without preheating up to 80 mm thickness.
|
Thickness (mm) |
ReH min (MPa) |
Rm (MPa) |
A5 min (%) |
KV min (J) at –20 °C longitudinal |
|---|---|---|---|---|
|
≤ 16 |
355 |
470–630 |
22 |
40 |
|
>16 ≤ 40 |
345 |
470–630 |
22 |
40 |
|
>40 ≤ 63 |
335 |
470–630 |
22 |
40 |
|
>63 ≤ 80 |
325 |
470–630 |
22 |
40 |
|
>80 ≤ 100 |
315 |
470–630 |
22 |
40 |
|
>100 ≤ 120 |
305 |
450–610 |
22 |
40 |
|
>120 ≤ 150 |
295 |
450–610 |
22 |
40 |
|
>150 ≤ 200 |
285–295* |
450–610 |
22 |
40 |
*Gangsteel guarantees 295 MPa up to 180 mm, 285 MPa to 200 mm.
Hardness: 140–180 HBW Density: 7.85 g/cm³
S355M is widely used when the service temperature is above –20 °C:
When the temperature drops below –20 °C, the low-temperature version S355ML is required.
Q1: S355M vs S355ML difference?A: Only impact test temperature. S355M = –20 °C (≥40 J), S355ML = –50 °C (≥27 J). Strength, chemistry, weldability identical.
Q2: Preheating required?A: No preheat up to 80 mm thickness. >80 mm: 75–100 °C max.
Q3: Z35 availability?A: Yes – large stock of S355M + Z35 ready for immediate delivery.
Q4: Density and hardness?A: Density 7.85 g/cm³, hardness 140–180 HBW.
Q5: NDT standard?A: 100 % UT EN 10160 S2/E2 included. S3/E3, MT, PT on request.
Q6: Maximum thickness?A: Up to 200 mm with full properties and certification.
Q7: Delivery time?A: Stock material 3–7 days worldwide.
Need EN10025-4 S355M high strength plates? Contact us now for best price and fastest delivery.
Email: admin@gangsteel.com WhatsApp/WeChat/Mobile: +86 135 9887 9167 Website: https://gangsteel.net/
Gangsteel – Real Factory. Real Stock. Real Fast Delivery.
