S275M vs S275ML EN 10025-4 Low Temp Comparison Supplier





S275M vs S275ML EN 10025-4 Low Temp Comparison Supplier

Gangsteel – China’s Largest Mill-Direct Supplier & Exporter of S275M vs S275ML EN 10025-4 Low Temperature Plates

Gangsteel is the most reliable supplier for both S275M and S275ML plates under EN 10025-4, with the largest combined stock in Asia – over 8,000 tons ready for immediate delivery in thickness 6–200 mm, width 1500–4200 mm, length up to 18 m. All plates are genuine TMCP produced by top mills (HBIS, Shougang) with full European approvals and third-party inspection (DNV, ABS, LR, BV, CCS, KR, TÜV, SGS).

We supply both grades with Z35 through-thickness quality in stock, 100 % UT EN 10160 S2/E2 standard, and full documentation.

Explore our complete en 10025 4 High Strength Structural Steel series, including the popular low-temperature grade en 10025 4 s275ml steel plate and en 10025 4 s275m steel plate, standard-temperature en 10025 4 s355m steel plate, mid-range en 10025 4 s355ml steel plate and en 10025 4 s420ml steel plate, higher-strength en 10025 4 s460m steel plate, and top-end en 10025 4 s460ml steel plate.



S275M vs S275ML – The Complete Low-Temperature Comparison

S275M and S275ML are identical twin grades in EN 10025-4 with the same chemistry, same strength, same weldability, and same TMCP delivery condition.

The only difference is the Charpy V-notch impact test temperature:

Property	S275M	S275ML	Winner for Low-Temp Projects
Standard	EN 10025-4	EN 10025-4	—
Impact Test Temperature	–20 °C	–50 °C	S275ML
Minimum KV (longitudinal)	≥40 J	≥27 J	S275ML(much safer below –20 °C)
Typical Actual KV (Gangsteel)	80–200 J at –20 °C	100–250 J at –50 °C	S275ML
Yield Strength ReH (MPa)	275 → 215–225 (by thickness)	Identical	Tie
Tensile Strength Rm (MPa)	370–530	Identical	Tie
Elongation A5 (%)	≥24	Identical	Tie
CEV max	0.38	Identical	Tie
Preheat-free Welding (mm)	Up to 100	Up to 100	Tie
Price (December 2025)	Baseline	+50–80 USD/ton	S275M cheaper, S275ML better value in cold
Market Share (Cold-Region Projects)	30–40 %	60–70 %	S275MLdominates

Bottom line:

• Service temperature ≥ –20 °C → S275M is sufficient and saves money
• Service temperature < –20 °C (cold storage, northern bridges, light offshore) → S275ML is mandatory and has become the default choice in 70 % of new projects

The price difference is easily recovered by the dramatically higher safety margin against brittle fracture in cold environments.



Chemical Composition – Identical for Both Grades

S275M and S275ML have exactly the same chemical requirements.

Ladle Analysis (max % unless noted)

Element	C	Si	Mn	P	S	Nb	V	Al min	Ti	Cr	Ni	Mo	Cu	N	CEV max
S275M / S275ML	0.14	0.50	1.50	0.030	0.025	0.05	0.10	0.020	0.05	0.30	0.30	0.10	0.55	0.015	0.38

Typical Gangsteel actual values: C 0.09–0.12 %, CEV 0.32–0.36.



Mechanical Properties – Identical Except Impact Temperature

Thickness (mm)	ReH min (MPa)	Rm (MPa)	A5 min (%)	KV min (J) at test temperature
≤16	275	370–530	24	S275M: 40 J @ –20 °C S275ML: 27 J @ –50 °C
16<t≤40	265	370–530	24	same
40<t≤63	255	370–530	24	same
63<t≤80	245	370–530	24	same
80<t≤100	235	370–530	24	same
100<t≤120	235	360–520	24	same
120<t≤150	225	360–520	24	same
150<t≤200	215–225*	360–520	24	same

*Gangsteel actual higher values. Hardness 130–170 HBW.



Weldability – Both Excellent (Identical)

Both grades have the same low CEV, so welding behaviour is identical:

• No preheating required up to 100 mm thickness
• Low-hydrogen consumables recommended
• Maximum heat input 3.0–4.0 kJ/mm to preserve HAZ toughness

Price Difference and Market Reality

Grade	Price Level (December 2025)	When to Choose
S275M	Baseline	Service ≥ –20 °C
S275ML	+50–80 USD/ton	Service < –20 °C (cold storage, northern infrastructure)

The extra cost of S275ML is easily justified by the higher safety margin in low temperatures.



Why Choose Gangsteel for S275M and S275ML Plates

• Largest combined stock of S275M and S275ML in Asia (8,000+ tons)
• Factory-direct price – 60–120 USD/ton lower than traders
• Full processing capability (cutting, beveling, drilling, rolling, priming)
• Z35 quality always in stock for both grades
• Immediate delivery worldwide
• Exported to 90+ countries with perfect documentation
• One-stop service – stock → processing → shipping



FAQ – Detailed Answers

Q1: S275M vs S275ML – which is better for cold storage warehouses?

A: S275ML is the standard choice for cold storage (used in 80 % of new projects) because it guarantees impact toughness at –50 °C instead of –20 °C. Most cold storage specifications require –40 °C or –50 °C design temperature for safety margin.

Q2: Are the mechanical properties identical except impact temperature?

A: Yes – yield strength, tensile strength, elongation, hardness, density, and weldability are exactly the same. Only the Charpy impact test temperature and minimum energy differ.

Q3: Price difference today?

A: S275ML is approximately 50–80 USD/ton higher than S275M (December 2025 market), but the extra toughness is worth it for any project below –20 °C service temperature.

Q4: Can I use S275M instead of S275ML to save money?

A: Only if your specification allows it and the lowest service temperature is above –20 °C. Most modern cold-region projects require S275ML.

Q5: Do you have both grades in stock right now?

A: Yes – very large stock of both S275M and S275ML in all common thicknesses, ready for immediate delivery.

Q6: Z35 availability for both grades?

A: Yes – large stock of S275M + Z35 and S275ML + Z35 ready.

Q7: Delivery time to Europe or USA?

A: From ready stock: 7–12 days to Rotterdam, Antwerp, Houston, or Los Angeles.

Contact Gangsteel Today

Need S275M or S275ML low-temp plates? Contact us for quotation within 2 hours.

Email: admin@gangsteel.com WhatsApp/WeChat/Mobile: +86 135 9887 9167 Website: https://gangsteel.net/

Gangsteel – Your Expert for Both S275M and S275ML Low-Temperature Plates.





Other technical date for EN 10025-4 S275M STEEL PLATE
