Gangsteel – China's Leading Mill-Direct Supplier & Exporter of S275M Mechanical Properties EN 10025-4 Data Sheet Steel Plates
Gangsteel is your definitive source for S275M mechanical properties EN 10025-4 data sheet steel plates, providing downloadable, heat-specific data sheets with verified mechanical, chemical, and physical properties for precise engineering and compliance. As a thermomechanically rolled (TMCP) weldable fine-grain structural steel under EN 10025-4:2004 (2019 revision), S275M's mechanical properties—minimum yield strength of 275 MPa, tensile range 370-530 MPa, elongation ≥24%, and impact toughness ≥40 J at –20 °C longitudinal—make it the benchmark for entry-level high-strength structural applications. We stock over 5,000 tons of S275M plates in thicknesses 6–200 mm, widths 1500–4200 mm, and lengths up to 18 meters, produced by premium mills like HBIS and Shougang with full PED 2014/68/EU and CPR 305/2011 certification. Each plate includes EN 10204-3.1/3.2 MTCs with full data sheet values, third-party inspections from DNV-GL, ABS, Lloyd's Register, Bureau Veritas, CCS, RINA, KR, TÜV, or SGS, Z25/Z35 through-thickness, and 100% UT EN 10160 S2/E2 testing.
S275M data sheets from Gangsteel include spectrographic chemistry, tensile/yield/elongation per EN ISO 6892-1, Charpy V-notch per EN ISO 148-1, hardness (HBW), density (7.85 g/cm³), and optional CTOD for fracture mechanics. CEV ≤0.38 ensures preheat-txt-free welding to 100 mm. Fast 3–7 day delivery and processing (cutting, beveling, drilling, rolling, priming). Download sample data sheet or request heat-specific PDF. Explore our en 10025 4 High Strength Structural Steel series. For grade overview, S275M Meaning EN 10025-4 Structural Steel Supplier.
The S275M data sheet under EN 10025-4:2004 (2019) is the official technical document detailing all verified mechanical properties of this TMCP weldable fine-grain structural steel, where "S" means structural, "275" nominal yield 275 MPa (transverse ≤16 mm), "M" TMCP delivery (900-1100 °C rolling + 20-40 °C/s cooling). Data sheets include ladle/product chemistry, mechanicals (yield, tensile, elongation, impact), physicals (density, hardness), and optional extras (Z-quality, CTOD).
TMCP's mechanical properties—low residual stress (<100 MPa), fine grains (ASTM 8-10), and CEV ≤0.38—yield superior weldability (no preheat to 100 mm), ductility (≥24% elongation), and fatigue life (>10^7 cycles at 140 MPa). Data sheets verify ReH 275 MPa min (actual 285-315 MPa typical), Rm 370-530 MPa, and KV per EN ISO 148-1 (10x10x55 mm, sub-size >40 mm). Density 7.85 g/cm³ and hardness 130-170 HBW support FEA (bilinear 2% hardening) and machining (0.2-0.3 mm/rev feeds).
S275M mechanical properties enable 5-10% thinner sections than S235JR under Eurocode 3, with partial factor γM0 = 1.0. Gangsteel data sheets are heat-traceable, supporting DNV-OS-B101 or AASHTO with CTOD (>0.3 mm at –20 °C) and KIc (>130 MPa√m at –20 °C). For chemical basis, S275M Chemical Composition EN 10025-4 Supplier; mechanical, S275M Mechanical Properties EN 10025-4 Plate Supplier.
|
Element |
Ladle Max (%) |
Product Deviation (%) |
Typical Actual (%) – Gangsteel Stock |
Role in Mechanical Properties |
|---|---|---|---|---|
|
C |
0.14 |
+0.02 |
0.09–0.12 |
Low C for weld ductility |
|
Si |
0.50 |
+0.05 |
0.20–0.40 |
Deoxidizer |
|
Mn |
1.50 |
+0.10 |
1.10–1.40 |
Strength for ReH 275 MPa |
|
P |
0.030 |
+0.005 |
≤0.018 |
Min P for toughness |
|
S |
0.025 |
+0.005 |
≤0.015 |
Low S for inclusion-free KV |
|
Nb |
0.05 |
+0.01 |
0.02–0.04 |
Pins grains for elongation |
|
V |
0.10 |
+0.02 |
0.04–0.08 |
Precipitates for Rm range |
|
Al min |
0.020 |
+0.030 (total) |
0.025–0.045 |
Deoxidizes for clean matrix |
|
Ti |
0.05 |
+0.03 |
0.01–0.03 |
Nitride for isotropy |
|
Cr |
0.30 |
+0.05 |
0.10–0.25 |
Controlled hardenability |
|
Ni |
0.30 |
+0.05 |
0.15–0.25 |
–20 °C transition |
|
Mo |
0.10 |
+0.03 |
≤0.05 |
HAZ stability |
|
Cu |
0.55 |
+0.03 |
0.20–0.35 |
Deoxidizer |
|
N |
0.015 |
+0.003 |
≤0.012 |
Low for properties |
|
CEV max |
0.38 |
N/A |
0.32–0.36 |
Weld index for ductility |
CEV = C + Mn/6 + (Cr+Mo+V)/5 + (Ni+Cu)/15. Equivs match. Full: S275M Chemical Composition EN 10025-4 Supplier.
|
Thickness (mm) |
ReH min (MPa) |
Rm (MPa) |
A5 min (%) |
KV min (J, long. –20 °C) |
|---|---|---|---|---|
|
≤16 |
275 |
370–530 |
24 |
40 |
|
16<t≤40 |
265 |
370–530 |
24 |
40 |
|
40<t≤63 |
255 |
370–530 |
24 |
40 |
|
63<t≤80 |
245 |
370–530 |
24 |
40 |
|
80<t≤100 |
235 |
370–530 |
24 |
40 |
|
100<t≤120 |
235 |
360–520 |
24 |
40 |
|
120<t≤150 |
225 |
360–520 |
24 |
40 |
|
150<t≤200 |
215–225* |
360–520 |
24 |
40 |
*Agreement >150 mm; Gangsteel 225 MPa to 180 mm. Hardness 130-170 HBW; density 7.85 g/cm³. Curves: S275M Mechanical Properties EN 10025-4 Plate Supplier.
S275M properties vs. family.
|
Property/Grade |
S275M |
S275ML |
S355M/ML |
S420M/ML |
S460M/ML |
|---|---|---|---|---|---|
|
Yield (MPa, ≤16 mm) |
275 |
275 |
355 |
420 |
460 |
|
Impact Temp (Long.) |
-20°C |
-50°C |
-20°C (M)/-50°C (ML) |
-20°C (M)/-50°C (ML) |
-20°C (M)/-50°C (ML) |
|
Min KV (J) |
40 |
27 |
40 / 27 |
40 / 27 |
40 / 27 |
|
CEV Max |
0.38 |
0.38 |
0.39 |
0.43 |
0.48 |
|
Elong. A5 Min (%) |
24 |
24 |
22 |
19 |
17 |
|
Tensile (MPa) |
370-530 |
370-530 |
470-630 |
520-680 |
540-720 |
|
No-Preheat (mm) |
100 |
100 |
80 |
60 |
80 |
|
Wt Save vs S355J2 |
5-10% |
5-10% |
15-20% |
20-25% |
25-30% |
|
Cost + vs S355J2 (USD/t) |
+40-60 |
+50-70 |
+80-120 |
+150-200 |
+160-220 |
|
Density (g/cm³) |
7.85 |
7.85 |
7.85 |
7.85 |
7.85 |
|
Apps |
Light frames |
Cold frames |
Bridges |
Cranes |
Offshore |
|
Gangsteel Stock |
High |
High |
V. High |
Medium |
Highest |
S275M entry high strength; vs S275ML, –20 °C KV; vs S355M, 20% lighter cost; vs S420M, better ductility/weldability. See S275M vs S275ML EN 10025-4 Low Temp Comparison Supplier.
S275M matches global shifts, TMCP aiding rolled precision.
|
Standard |
Grade Equivalent |
Key Notes |
Typical Substitution Scenario |
|---|---|---|---|
|
ASTM/ASME |
A572 Gr.42 + Z35 |
Yield near; LT test for –20 °C. |
US light structures, AISC 360. |
|
JIS G 3106 |
SM400B |
Core match; scale per JIS G 0404. |
Asian utility frames. |
|
GB/T 1591 |
Q275C |
KV at 0 °C; dual China-EU. |
Domestic chill with exports. |
|
BS EN 10025-3 |
S275N |
S275M adds TMCP fine-grain. |
UK low-temp general. |
|
API 2H |
Grade 42 |
S275M enhances LT; CTOD optional. |
Shallow-water jackets. |
Indicative; S275M for –20 °C. Related: en 10025 4 s420ml steel plate.
S275M's TMCP simplicity suits Eurocode 3, trimming 10% vs. S235 in frames while padding impacts. Key fields:
Tips: Use E42xx fillers; heat ≤1.8 kJ/cm HAZ. Form 1.8t cold; heat 700–850 °C. Green: 100% recycle, 15% CO2 drop vs. HR TMCP. Gangsteel does plasma cuts (±1.5 mm) and zinc (35 µm) for fixings.
Gangsteel redefines S275M sourcing:
To 78+ hubs: Oslo (10 days), Vancouver (15 days), under Incoterms 2020.
Q1: S275M vs S275ML?
A: KV only: S275M ≥40J –20 °C for mild, S275ML ≥27J –50 °C for chill. Rest match—ML < –20 °C EN 1991-1-3 snow.
Q2: S275M weld preheat?
A: No; CEV ≤0.38 to 100 mm H4 electrodes. Bulk: 75–120 °C via EN 1011. CET per batch PQR.
Q3: S275M for vessels?
A: Yes—PED I low EN 10028. t-scale; VI EN 10228.
Q4: S275M vs S355M cost?
A: 50-80 USD/ton premium for TMCP, offset 15% thinness. FOB: ~680–780 USD/ton (25 mm).
Q5: Z for S275M?
A: Z25 base; Z35 for pulls. EN 10164 Cl.1.
Q6: S275M = A572 Gr.42?
A: Yield close (275 vs 290 MPa); S275M finer grain. AISC ok w/ impact.
Q7: S275M custom time?
A: Stock: 1–3 days. Fab: 2–4 days. Roll: 3–4 weeks; rush <4 MT.
Join Gangsteel for EN 10025-4 S275M ease.
