Gangsteel – China's Leading Mill-Direct Supplier & Exporter of S355ML Equivalent EN 10025-4 International Steel Plates
Gangsteel is the global authority for S355ML equivalent EN 10025-4 international steel plates, providing verified cross-references and direct substitutes that meet or exceed EN 10025-4 specifications while complying with ASTM, JIS, GB/T, API, and other worldwide standards. We stock over 5,000 tons of S355ML and its equivalents in thicknesses 6–200 mm, widths 1500–4200 mm, and lengths up to 18 meters, all TMCP-processed for optimal weldability and low-temperature toughness. Produced by top mills like HBIS and Shougang with full PED 2014/68/EU and CPR 305/2011 certification, our plates include EN 10204-3.1/3.2 MTCs with detailed equivalent mapping, third-party inspections from DNV-GL, ABS, Lloyd's Register, Bureau Veritas, CCS, RINA, KR, TÜV, or SGS, and Z25/Z35 through-thickness quality in stock.
S355ML's international equivalents allow seamless substitution in multinational projects, reducing procurement complexity and costs while maintaining the grade's core advantages: 355 MPa minimum yield, CEV ≤0.39 for preheat-free welding up to 80 mm, and ≥27 J Charpy V-notch at –50 °C longitudinal. Whether you're sourcing for European offshore wind, American bridge retrofits, or Asian shipyards, Gangsteel offers dual-certified plates with precise property matching. Density 7.85 g/cm³ and hardness 140-180 HBW ensure consistent performance across standards. Fast 3–7 day delivery and processing (cutting, beveling, drilling, rolling, priming) complete the service. Explore our en 10025 4 High Strength Structural Steel for the full series. For grade fundamentals, see S355ML Meaning EN 10025-4 Structural Steel Supplier.
S355ML equivalent under EN 10025-4:2004 (2019) refers to international steel grades that match or closely approximate S355ML's properties—a thermomechanically rolled (TMCP) weldable fine-grain structural steel with 355 MPa minimum yield strength and ≥27 J Charpy V-notch at –50 °C longitudinally. The designation "S355ML" means "S" for structural, "355" nominal yield (MPa, ≤16 mm transverse), "M" TMCP delivery (900-1100 °C rolling + 20-40 °C/s cooling), and "L" low-temperature impact.
Equivalents are essential for global projects, enabling substitution without re-qualification under codes like Eurocode 3 (EN 1993-1-1), DNV-OS-B101, or AASHTO. TMCP's fine grains (ASTM 8-10) and low CEV ≤0.39 provide superior weldability and isotropy versus normalized or QT alternatives, with ductility ≥22% elongation and fatigue >10^7 cycles at 160 MPa. Density 7.85 g/cm³ and hardness 140-180 HBW are consistent across equivalents.
Gangsteel supplies S355ML with dual or triple certification (e.g., EN + ASTM + GB), ideal for hybrid specs. For chemical basis, S355ML Chemical Composition EN 10025-4 Supplier; for mechanical, S355ML Mechanical Properties EN 10025-4 Plate Supplier.
Equivalents share similar chemistry; S355ML tight for TMCP.
|
Element |
Ladle Max (%) |
Product Deviation (%) |
Typical Actual (%) – Gangsteel Stock |
Role in Equivalent Performance |
|---|---|---|---|---|
|
C |
0.14 |
+0.02 |
0.09–0.12 |
Low C for weld in all equivs |
|
Si |
0.50 |
+0.05 |
0.20–0.40 |
Deoxidizer; stable ferrite |
|
Mn |
1.60 |
+0.10 |
1.20–1.50 |
Strength for yield match |
|
P |
0.025 |
+0.005 |
≤0.018 |
Min P for toughness equiv |
|
S |
0.020 |
+0.005 |
≤0.015 |
Low S for inclusion-free KV |
|
Nb |
0.05 |
+0.01 |
0.02–0.04 |
Grain refiner for TMCP equiv |
|
V |
0.10 |
+0.02 |
0.04–0.08 |
Precipitation in all |
|
Al min |
0.020 |
+0.030 (total) |
0.025–0.045 |
Deoxidizer for clean matrix |
|
Ti |
0.05 |
+0.03 |
0.01–0.03 |
Nitride for isotropy |
|
Cr |
0.30 |
+0.05 |
0.10–0.25 |
Controlled hardenability |
|
Ni |
0.50 |
+0.05 |
0.20–0.40 |
Low-temp transition |
|
Mo |
0.10 |
+0.03 |
≤0.05 |
HAZ stability |
|
Cu |
0.55 |
+0.03 |
0.20–0.35 |
Deoxidizer |
|
N |
0.015 |
+0.003 |
≤0.012 |
Low for properties |
|
CEV max |
0.39 |
N/A |
0.32–0.38 |
Weld index for equiv |
CEV = C + Mn/6 + (Cr+Mo+V)/5 + (Ni+Cu)/15. Equivs like Q355E match ±0.02%. Full: S355ML Chemical Composition EN 10025-4 Supplier.
Equivalents align; S355ML TMCP isotropy edge.
|
Thickness (mm) |
ReH min (MPa) |
Rm (MPa) |
A5 min (%) |
KV min (J, long. –50 °C) |
|---|---|---|---|---|
|
≤16 |
355 |
470–630 |
22 |
27 |
|
16<t≤40 |
345 |
470–630 |
22 |
27 |
|
40<t≤63 |
335 |
470–630 |
22 |
27 |
|
63<t≤80 |
325 |
470–630 |
22 |
27 |
|
80<t≤100 |
315 |
470–630 |
22 |
27 |
|
100<t≤120 |
305 |
450–610 |
22 |
27 |
|
120<t≤150 |
295 |
450–610 |
22 |
27 |
|
150<t≤200 |
285–295* |
450–610 |
22 |
27 |
*Agreement >150 mm; Gangsteel 295 MPa to 180 mm. Hardness 140-180 HBW; density 7.85 g/cm³. Curves: S355ML Mechanical Properties EN 10025-4 Plate Supplier.
S355ML equiv properties vs. family.
|
Property/Grade |
S275M/ML |
S355M |
S355ML |
S420M/ML |
|---|---|---|---|---|
|
Yield (MPa, ≤16 mm) |
275 |
355 |
355 |
420 |
|
Impact Temp (Long.) |
-20°C (M)/-50°C (ML) |
-20°C |
-50°C |
-20°C (M)/-50°C (ML) |
|
Min KV (J) |
40/-20°C; 27/-50°C |
40/-20°C |
27/-50°C |
40/-20°C; 27/-50°C |
|
CEV Max |
0.38 |
0.39 |
0.39 |
0.43 |
|
Elong. A5 Min (%) |
24 |
22 |
22 |
19 |
|
Tensile (MPa) |
370-530 |
470-630 |
470-630 |
520-680 |
|
No-Preheat (mm) |
100 |
80 |
80 |
60 |
|
Wt Save vs S355J2 |
5-10% |
15-20% |
15-20% |
20-25% |
|
Cost + vs S355J2 (USD/t) |
+40-60 |
+80-120 |
+100-150 |
+150-200 |
|
Density (g/cm³) |
7.85 |
7.85 |
7.85 |
7.85 |
|
Apps |
Light frames |
Bridges |
Offshore |
Cranes |
|
Gangsteel Stock |
High |
V. High |
Highest |
Med |
S355ML equiv balanced; vs S355M, –50 °C KV; vs S275ML, 30% stronger; vs S420ML, ductility. See S355M vs S355ML EN 10025-4 Steel Plate Comparison Supplier.
S355ML international equivalents for seamless substitution.
|
Standard |
Equivalent Grade |
Key Match Notes |
Typical Use Case |
|---|---|---|---|
|
ASTM/ASME |
A572 Gr.50 + Z35 |
Yield 345 MPa; –50 °C KV add; density 7.85 |
U.S. offshore equiv |
|
JIS G 3106 |
SM490A |
Rm 490 MPa; –40 °C KV; ductility same |
Japanese marine equiv |
|
GB/T 1591 |
Q355E |
Low-temp exact; CEV similar |
China-EN hybrid equiv |
|
API 2W |
Grade 50 |
Offshore weldable; KV >27 J |
Gulf/Baltic platforms equiv |
|
EN 10025-6 |
S355QL |
QT alt; S355ML cheaper/no distortion |
Heavy lifts equiv |
Indicative; TMCP S355ML HAZ better. Dual-cert. Full: S355ML Equivalent Material EN 10025-4 Plate Supplier.
Equivalents for flexible sourcing; S355ML TMCP for field.
Notes: Interpass 150°C; ER50-2. FEA equiv properties, 2% hardening. Eco: 97% recycle, 20% CO2 save. Gangsteel V-50°, UT S4. For weld, S355ML/NL Weldability EN 10025-4 Fine Grain Supplier; data S355ML Data Sheet EN 10025-4 Steel Properties Supplier.
To 92+ countries: Rotterdam 7 days. For specs, S355ML Specification EN 10025-4 Steel Plate Supplier.
Q1: Best S355ML equiv for U.S. projects?
A: A572 Gr.50 + Z35; yield 345 MPa close, add –50 °C KV for full match. A633 Gr.C alt for normalized. Dual-cert for AISC 360; Gangsteel supplies U.S. stamps.
Q2: JIS SM490A vs S355ML equiv?
A: SM490A Rm 490 MPa equiv, –40 °C KV standard; S355ML TMCP finer HAZ. For Japanese-Polish JV, SM490A cost-effective; Gangsteel offers both with JIS certs.
Q3: Q355E (GB) substitution for S355ML?
A: Exact low-temp match per GB/T 1591; CEV similar. Ideal China-EU; Gangsteel dual EN/GB MTCs for Belt & Road.
Q4: API 2W Gr.50 for offshore equiv?
A: Yes, weldable equiv; S355ML LT superior (CTOD >0.25 mm opt). For Gulf/Baltic, API RP 2Z; stock with DNV approval.
Q5: S355QL (EN 10025-6) alt equiv?
A: QT version same strength; S355ML cheaper, no distortion. For lifts, QL if >500 MPa needed; both stocked.
Q6: Equiv price diff?
A: Equivs 10-30 USD/t cheaper (local stock); S355ML premium for TMCP. FOB 680-780 USD/t equiv (25 mm).
Q7: Lead time for S355ML equivs?
A: Stock 2-4 days; processed 3-6 days; mill 4 weeks. Dual-cert +1 week; air <10 MT 24-48 hrs.
For S355ML equivalent plates, quote now.
