S460ML=Z35 EN 10025-4 Z35 Through-Thickness Supplier

Gangsteel – China's Largest Mill-Direct Supplier & Exporter of S460ML=Z35 EN 10025-4 Z35 Through-Thickness Plates

Gangsteel is the world’s most experienced and reliable supplier for S460ML=Z35 EN 10025-4 Z35 through-thickness plates, with the largest dedicated stock of Z35-certified S460ML in Asia – over 4,000 tons always ready in thickness 10–200 mm, width 1500–4200 mm, length up to 18 meters. All plates are genuine TMCP produced by top mills (HBIS, Shougang) with full European approvals (PED 2014/68/EU, CPR 305/2011).

We supply S460ML=Z35 with mandatory Z35 quality (≥35 % reduction of area per EN 10164 Class 3), full EN 10204-3.1/3.2 certificates, third-party inspection (DNV-GL, ABS, LR, BV, CCS, KR, TÜV, SGS), and 100 % UT EN 10160 S3/E3 standard.

Immediate delivery worldwide in 3–7 days. Full processing services: plasma/oxy cutting, beveling, drilling, rolling, priming.

Explore our complete en 10025 4 High Strength Structural Steel series and the standard version en 10025 4 s460ml steel plate.

What is S460ML=Z35 EN 10025-4 Z35 Through-Thickness Plate?

S460ML=Z35is a thermomechanically rolled (TMCP) weldable fine-grain structural steel under EN 10025-4:2004 (2019 revision) with additional Z35 through-thickness quality per EN 10164 Class 3.

S460ML= structural steel, 460 MPa yield, TMCP delivery, low-temperature toughness (–50 °C)
=Z35= guaranteed through-thickness ductility: minimum 35 % reduction of area (RA_z) in Z-direction tensile test (three specimens per heat, average ≥35 %, single ≥25 %)

Z35 quality prevents lamellar tearing in highly stressed welded joints where tension acts perpendicular to the plate surface (T-joints, cruciform welds, gusset plates, jacket leg nodes, etc.).

S460ML=Z35 is the preferred grade for:

Offshore wind jackets and monopile transition pieces
Jack-up rig leg chords and rack plates
Heavy crane base and boom sections
Seismic-resistant building columns
Thick plate welded structures under high Z-direction stress

Chemical Composition – Optimized for Z35 Quality

Element	Ladle Max (%)	Product Deviation (%)	Typical Actual (%) – Gangsteel Z35 Stock	Role in Z35 Performance
C	0.16	+0.02	0.09–0.12	Low C for clean HAZ
Si	0.60	+0.05	0.20–0.40	Deoxidizer
Mn	1.70	+0.10	1.20–1.50	Strength without Z-weakness
P	0.025	+0.005	≤0.015	Min P for Z-cohesion
S	0.010	+0.003	≤0.005 (VD/VAR standard)	Ultra-low S for Z35 RA
Nb	0.05	+0.01	0.025–0.045	Grain refiner for uniform Z
V	0.12	+0.02	0.05–0.10	Precipitation
Al min	0.020	+0.030	0.030–0.050	Deoxidizer for clean Z
Ti	0.05	+0.03	0.015–0.035	Nitride for Z-isotropy
Cr	0.30	+0.05	0.10–0.25	Controlled
Ni	0.80	+0.05	0.30–0.60	–50 °C Z-toughness
Mo	0.20	+0.03	≤0.10	HAZ Z-stability
Cu	0.55	+0.03	0.20–0.40	Deoxidizer
N	0.025	+0.003	≤0.012	Low for Z-cleanliness
CEV max	0.48	N/A	0.42–0.46	Ultra-weld for Z-joints

S ≤0.005 % + Ca treatment standard for Z35. Full: S460ML Chemical Composition EN 10025-4 Supplier.

Mechanical Properties – Full Thickness Range up to 200 mm (Transverse)

Thickness (mm)	ReH min (MPa)	Rm (MPa)	A5 min (%)	KV min (J, long. –50 °C)	Z35 RA min (%)
≤16	460	540–720	17	27	35
16<t≤40	440	540–720	17	27	35
40<t≤63	430	540–720	17	27	35
63<t≤80	410	540–720	17	27	35
80<t≤100	400	540–720	17	27	35
100<t≤120	385	530–710	17	27	35
120<t≤150	370	530–710	17	27	35
150<t≤200	350–380*	530–710	17	27	35

*Gangsteel guarantees higher values in thick plates. Hardness 160–210 HBW; density 7.85 g/cm³. Curves: S460ML Mechanical Properties EN 10025-4 Plate Supplier.

Comparison Within the Standard

S460ML=Z35 vs. family.

Property/Grade	S275M/ML	S355M	S460M	S460ML=Z35	S500M/ML
Yield (MPa, ≤16 mm)	275	355	460	460	500
Impact Temp (Long.)	-20°C (M)/-50°C (ML)	-20°C	-20°C	-50°C	-20°C (M)/-50°C (ML)
Min KV (J)	40/-20°C; 27/-50°C	40/-20°C	40/-20°C	27/-50°C	40/-20°C; 27/-50°C
CEV Max	0.38	0.39	0.48	0.48	0.51
Elong. A5 Min (%)	24	22	17	17	17
Tensile (MPa)	370-530	470-630	540-720	540-720	570-720
No-Preheat (mm)	100	80	80	80	60
Wt Save vs S355J2	5-10%	15-20%	25-30%	25-30%	30-35%
Cost + vs S355J2 (USD/t)	+40-60	+80-120	+140-180	+160-220	+200-250
Density (g/cm³)	7.85	7.85	7.85	7.85	7.85
Apps	Light frames	Bridges	Heavy structures	Z35 offshore	Ultra-heavy
Gangsteel Stock	High	V. High	High	Highest	Limited

S460ML=Z35 "Z35 enhanced high strength"; vs S355ML, 30% higher yield; vs S460M, –50 °C KV; vs S500ML, better ductility/weldability. See S460M vs S460ML EN 10025-4 Impact Comparison Supplier.

Equivalent International Grades

Z35 equivs.

Standard	Equivalent Grade	Key Match Notes	Typical Use Case
ASTM/ASME	A913 Gr.65 + Z35	Yield 450 MPa; Z35 –50 °C	U.S. Z35 high-rise
JIS G 3106	SM570 + Z35	Rm 570 MPa; ductility Z35	Japanese Z35 offshore
GB/T 1591	Q460E + Z35	Low-temp Z35	China-EN Z35 projects
API 2W	Grade 60 + Z35	Offshore Z35 KV	Z35 platforms
EN 10025-6	S460QL + Z35	QT Z35; S460ML cheaper	Heavy Z35 lifts

Indicative; TMCP Z35 better. Dual-cert. Full: S460ML Equivalent Material EN 10025-4 Plate Supplier.

Applications & Design Considerations for S460ML=Z35

Z35 for Eurocode 3, 25-30% less steel in welds.

Offshore: Jackets, Z35 tears; fatigue 10^8 cycles 140 MPa DNV-RP-C203.
Seismic: Braces, enhanced KV; HIC Class 1.
Pipes: Penstocks, A5 3% drifts EN 1998-1; C4M <0.08 mm/yr epoxy.
Fab: T-joints, 3t radius; 55 yr ICCP.

Notes: Interpass 150°C; ER50-2. FEA Z35 properties, 2% hardening. Eco: 97% recycle, 20% CO2 save. Gangsteel V-50°, UT S4. For weld, S355ML/NL Weldability EN 10025-4 Fine Grain Supplier; data S355ML Data Sheet EN 10025-4 Steel Properties Supplier.

Why Choose Gangsteel for S460ML=Z35

4,000+ t Z35 stock.
Mill-direct 80-140 USD/t save; >700 MT tiers.
Process: laser ±0.3 mm, X-bevel, 150 mm bore, 450 mm roll, C5H 200 µm.
Cert: ISO 9001/14001, NACE sour, EN 1090 EXC4.
Legacy: Siemens 1,200+ t Z35 (Hornsea), Total (Ichthys)—OTIF 100%.

To 92+ countries: Rotterdam 6 days. For specs, S355ML Specification EN 10025-4 Steel Plate Supplier; comparison S355ML vs S355J2 EN 10025-4 Strength Comparison Supplier.

Summary

S460ML=Z35 EN 10025-4 plates from Gangsteel provide guaranteed Z35 through-thickness ductility (RA_z ≥35%), 460 MPa yield, –50 °C toughness, and TMCP weldability for critical structural welds in offshore, seismic, and heavy fabrication. Stocked in 6–200 mm with full certification, Z35 eliminates lamellar tearing risk where standard Z25 fails. Contact for immediate supply.

FAQ

Q1: What is Z35 in S460ML?

A: Z35 = ≥35% reduction of area in Z-direction tensile test (EN 10164 Cl.3), preventing lamellar tearing in welds under perpendicular stress. Mandatory for T-joints in offshore jackets.

Q2: S460ML=Z35 vs S460ML difference?

A: Z35 adds through-thickness guarantee (RA_z ≥35%); standard S460ML is Z25 (≥25%). Yield/impact same—Z35 for high-risk welds.

Q3: Welding preheat for S460ML=Z35?

A: None to 80 mm (CEV 0.42-0.46); low-H E7018 H4. Thicker: 75-120 °C (EN ISO 13916). TMCP preserves Z35 in HAZ.

Q4: S460ML=Z35 for pressure vessels?

A: Yes, PED III (EN 13445); derate >63 mm. UT S3/E3; RT opt seams. Z35 aids nozzle welds.

Q5: Z35 price premium?

A: +20-40 USD/t vs standard S460ML; included in our Z35 stock.

Q6: ASTM equiv for S460ML=Z35?

A: A913 Gr.65 + Z35; yield 450 MPa, Z35 –50 °C. Dual-cert stocked.

Q7: Custom S460ML=Z35 lead time?

A: Stock 1-3 days; processed 2-5 days; mill 3-5 weeks. 95% OTIF; air <10 MT 24-48 hrs.

Contact Gangsteel

For S460ML=Z35 plates, quote now.

Email: admin@gangsteel.com WhatsApp/WeChat/Mobile: +86 135 9887 9167 Website: https://gangsteel.net/

Gangsteel—Z35 Guaranteed, Delivered Direct.
