S460M vs S460ML EN 10025-4 Impact Comparison Supplier





S460M vs S460ML EN 10025-4 Impact Comparison Supplier

Gangsteel – China's Largest Mill-Direct Supplier & Exporter of S460M vs S460ML EN 10025-4 Impact Tested Steel Plates

Gangsteel is the most reliable supplier for both S460M and S460ML plates under EN 10025-4, with the largest combined stock in Asia – over 8,000 tons ready for immediate delivery in thickness 6–200 mm, width 1500–4200 mm, length up to 18 m. All plates are genuine TMCP produced by top mills (HBIS, Shougang) with full European approvals and third-party inspection (DNV, ABS, LR, BV, CCS, KR, TÜV, SGS).

We supply both grades with Z35 through-thickness quality in stock, 100 % UT EN 10160 S2/E2 standard, and full documentation.

Explore our complete en 10025 4 High Strength Structural Steel series, including the popular low-temperature grade en 10025 4 s460ml steel plate and the widely used en 10025 4 s355ml steel plate.



S460M vs S460ML – The Complete Impact Toughness Comparison

S460M and S460ML are identical twin grades in EN 10025-4 with the same chemistry, same strength, same weldability, and same TMCP delivery condition.

The only difference is the Charpy V-notch impact test temperature:

Property	S460M	S460ML	Winner for Impact-Critical Projects
Standard	EN 10025-4	EN 10025-4	—
Impact Test Temperature	–20 °C	–50 °C	S460ML
Minimum KV (longitudinal)	≥40 J	≥27 J	S460ML(tougher at lower temp)
Typical Actual KV (Gangsteel)	80–200 J at –20 °C	100–250 J at –50 °C	S460ML
Yield Strength ReH (MPa)	460 → 350–380 (by thickness)	Identical	Tie
Tensile Strength Rm (MPa)	540–720	Identical	Tie
Elongation A5 (%)	≥17	Identical	Tie
CEV max	0.48	Identical	Tie
Preheat-free Welding (mm)	Up to 80	Up to 80	Tie
Price (November 2025)	Baseline	+80–150 USD/ton	S460M cheaper, S460ML better value in cold
Market Share (Offshore Wind)	15–25 %	75–85 %	S460MLdominates

Bottom line: If your lowest service temperature is above –20 °C → S460M is sufficient and slightly cheaper. If your lowest service temperature is below –20 °C (most offshore wind, Arctic, cold-region bridges) → S460ML is mandatory and has become the default choice in 90 % of new projects.

The price difference is easily justified by the much higher safety margin against brittle fracture in low temperatures.



Chemical Composition – Identical for Both Grades

S460M and S460ML have exactly the same chemical requirements.

Ladle Analysis (max % unless noted)

Element	C	Si	Mn	P	S	Nb	V	Al min	Ti	Cr	Ni	Mo	Cu	N	CEV max
S460M / S460ML	0.16	0.60	1.70	0.025	0.020	0.05	0.12	0.020	0.05	0.30	0.80	0.20	0.55	0.025	0.48

Typical Gangsteel actual values: C 0.10–0.14 %, CEV 0.42–0.46.

Full chemical data: S355ML Chemical Composition EN 10025-4 Supplier (same composition as S460ML).



Mechanical Properties – Identical Except Impact Temperature

Thickness (mm)	ReH min (MPa)	Rm (MPa)	A5 min (%)	KV min (J) at test temperature
≤16	460	540–720	17	S460M: 40 J @ –20 °C S460ML: 27 J @ –50 °C
16<t≤40	440	540–720	17	same
40<t≤63	430	540–720	17	same
63<t≤80	410	540–720	17	same
80<t≤100	400	540–720	17	same
100<t≤150	370–385	530–710	17	same
150<t≤200	350–380*	530–710	17	same

Gangsteel actual higher values. Hardness 160–210 HBW. Full tables: S355ML Mechanical Properties EN 10025-4 Plate Supplier (same as S460ML).



Weldability – Both Excellent (Identical)

Both grades have the same low CEV, so welding behaviour is identical:

• No preheating required up to 80 mm thickness
• Low-hydrogen consumables recommended
• Maximum heat input 3.5–4.5 kJ/mm to preserve HAZ toughness



Price Difference and Market Reality

Grade	Price Level (November 2025)	When to Choose
S460M	Baseline	Service temperature ≥ –20 °C
S460ML	+80–150 USD/ton	Service temperature < –20 °C (offshore wind, Arctic, cold bridges)

The extra cost of S460ML is easily justified by the much higher safety margin against brittle fracture in low temperatures.



Why Choose Gangsteel for S460M and S460ML Plates

• Largest combined stock of S460M and S460ML in Asia (8,000+ tons)
• Factory-direct price – 60–120 USD/ton lower than traders
• Full processing capability (cutting, beveling, drilling, rolling, priming)
• Z35 quality always in stock for both grades
• Immediate delivery worldwide
• Exported to 90+ countries with perfect documentation
• One-stop service – stock → processing → shipping



FAQ – Detailed Answers

Q1: S460M vs S460ML – which is better for offshore wind?

A: S460ML is now the standard choice for offshore wind (used in 90 % of new projects) because it guarantees impact toughness at –50 °C instead of –20 °C. Most offshore wind specifications (DNV-OS-B101, Norsok M-120) require –40 °C or –50 °C design temperature for safety margin.

Q2: Are the mechanical properties identical except impact temperature?

A: Yes – yield strength, tensile strength, elongation, hardness, density, and weldability are exactly the same. Only the Charpy impact test temperature and minimum energy differ.

Q3: Price difference today?

A: S460ML is approximately 80–150 USD/ton higher than S460M (November 2025 market), but the extra toughness is worth it for any project below –20 °C service temperature.

Q4: Can I use S460M instead of S460ML to save money?

A: Only if your specification allows it and the lowest service temperature is above –20 °C. Most modern offshore and cold-region projects require S460ML.

Q5: Do you have both grades in stock right now?

A: Yes – very large stock of both S460M and S460ML in all common thicknesses, ready for immediate delivery.

Q6: Z35 availability for both grades?

A: Yes – large stock of S460M + Z35 and S460ML + Z35 ready.

Q7: Delivery time to Europe or USA?

A: From ready stock: 7–12 days to Rotterdam, Antwerp, Houston, or Los Angeles.



Contact Gangsteel Today

Need S460M or S460ML plates? Contact us for quotation within 2 hours.

Email: admin@gangsteel.com WhatsApp/WeChat/Mobile: +86 135 9887 9167 Website: https://gangsteel.net/

Gangsteel – Your Expert for Both S460M and S460ML Impact Tested Plates.
