S460ML+Z35 EN 10025-4 Through-Thickness Plate Supplier
Gangsteel – China's Largest Mill-Direct Supplier & Exporter of S460ML+Z35 EN 10025-4 Through-Thickness Plates
Gangsteel is the world’s most experienced and reliable supplier for S460ML+Z35 EN 10025-4 through-thickness plates, with the largest dedicated stock of Z35-certified S460ML in Asia – over 4,000 tons always ready in thickness 10–200 mm, width 1500–4200 mm, length up to 18 meters. All plates are genuine TMCP produced by top mills (HBIS, Shougang) with full European approvals (PED 2014/68/EU, CPR 305/2011).
We supply S460ML+Z35 with mandatory Z35 quality (≥35 % reduction of area per EN 10164 Class 3), full EN 10204-3.1/3.2 certificates, third-party inspection (DNV-GL, ABS, LR, BV, CCS, KR, TÜV, SGS), and 100 % UT EN 10160 S3/E3 standard.
Immediate delivery worldwide in 3–7 days. Full processing services: plasma/oxy cutting, beveling, drilling, rolling, priming.
Explore our complete en 10025 4 High Strength Structural Steel series and the standard version en 10025 4 s460ml steel plate.
What is S460ML+Z35 EN 10025-4 Through-Thickness Plate?
S460ML+Z35is a thermomechanically rolled (TMCP) weldable fine-grain structural steel under EN 10025-4:2004 (2019 revision) with additional Z35 through-thickness quality per EN 10164 Class 3.
- S460ML= structural steel, 460 MPa yield, TMCP delivery, low-temperature toughness (–50 °C)
- +Z35= guaranteed through-thickness ductility: minimum 35 % reduction of area (RA_z) in Z-direction tensile test (three specimens per heat, average ≥35 %, single ≥25 %)
Z35 quality prevents lamellar tearing in highly stressed welded joints where tension acts perpendicular to the plate surface (T-joints, cruciform welds, gusset plates, jacket leg nodes, etc.).
S460ML+Z35 is the preferred grade for:
- Offshore wind jackets and monopile transition pieces
- Jack-up rig leg chords and rack plates
- Heavy crane base and boom sections
- Seismic-resistant building columns
- Thick plate welded structures under high Z-direction stress
Chemical Composition – Optimized for Z35 Quality
|
Element |
Ladle Max (%) |
Product Deviation (%) |
Typical Actual (%) – Gangsteel Z35 Stock |
Role in Z35 Performance |
|---|---|---|---|---|
|
C |
0.16 |
+0.02 |
0.09–0.12 |
Low C for clean HAZ |
|
Si |
0.60 |
+0.05 |
0.20–0.40 |
Deoxidizer |
|
Mn |
1.70 |
+0.10 |
1.20–1.50 |
Strength without Z-weakness |
|
P |
0.025 |
+0.005 |
≤0.015 |
Min P for Z-cohesion |
|
S |
0.010 |
+0.003 |
≤0.005 (VD/VAR standard) |
Ultra-low S for Z35 RA |
|
Nb |
0.05 |
+0.01 |
0.025–0.045 |
Grain refiner for uniform Z |
|
V |
0.12 |
+0.02 |
0.05–0.10 |
Precipitation |
|
Al min |
0.020 |
+0.030 |
0.030–0.050 |
Deoxidizer for clean Z |
|
Ti |
0.05 |
+0.03 |
0.015–0.035 |
Nitride for Z-isotropy |
|
Cr |
0.30 |
+0.05 |
0.10–0.25 |
Controlled |
|
Ni |
0.80 |
+0.05 |
0.30–0.60 |
–50 °C Z-toughness |
|
Mo |
0.20 |
+0.03 |
≤0.10 |
HAZ Z-stability |
|
Cu |
0.55 |
+0.03 |
0.20–0.40 |
Deoxidizer |
|
N |
0.025 |
+0.003 |
≤0.012 |
Low for Z-cleanliness |
|
CEV max |
0.48 |
N/A |
0.42–0.46 |
Ultra-weld for Z-joints |
S ≤0.005 % + Ca treatment standard for Z35. Full: S460ML Chemical Composition EN 10025-4 Supplier.
Mechanical Properties – Full Thickness Range up to 200 mm (Transverse)
|
Thickness (mm) |
ReH min (MPa) |
Rm (MPa) |
A5 min (%) |
KV min (J, long. –50 °C) |
Z35 RA min (%) |
|---|---|---|---|---|---|
|
≤16 |
460 |
540–720 |
17 |
27 |
35 |
|
16<t≤40 |
440 |
540–720 |
17 |
27 |
35 |
|
40<t≤63 |
430 |
540–720 |
17 |
27 |
35 |
|
63<t≤80 |
410 |
540–720 |
17 |
27 |
35 |
|
80<t≤100 |
400 |
540–720 |
17 |
27 |
35 |
|
100<t≤120 |
385 |
530–710 |
17 |
27 |
35 |
|
120<t≤150 |
370 |
530–710 |
17 |
27 |
35 |
|
150<t≤200 |
350–380* |
530–710 |
17 |
27 |
35 |
*Gangsteel guarantees higher values in thick plates. Hardness 160–210 HBW; density 7.85 g/cm³. Curves: S460ML Mechanical Properties EN 10025-4 Plate Supplier.
Comparison Within the Standard
S460ML+Z35 vs. family.
|
Property/Grade |
S275M/ML |
S355M |
S460M |
S460ML+Z35 |
S500M/ML |
|---|---|---|---|---|---|
|
Yield (MPa, ≤16 mm) |
275 |
355 |
460 |
460 |
500 |
|
Impact Temp (Long.) |
-20°C (M)/-50°C (ML) |
-20°C |
-20°C |
-50°C |
-20°C (M)/-50°C (ML) |
|
Min KV (J) |
40/-20°C; 27/-50°C |
40/-20°C |
40/-20°C |
27/-50°C |
40/-20°C; 27/-50°C |
|
CEV Max |
0.38 |
0.39 |
0.48 |
0.48 |
0.51 |
|
Elong. A5 Min (%) |
24 |
22 |
17 |
17 |
17 |
|
Tensile (MPa) |
370-530 |
470-630 |
540-720 |
540-720 |
570-720 |
|
No-Preheat (mm) |
100 |
80 |
80 |
80 |
60 |
|
Wt Save vs S355J2 |
5-10% |
15-20% |
25-30% |
25-30% |
30-35% |
|
Cost + vs S355J2 (USD/t) |
+40-60 |
+80-120 |
+140-180 |
+160-220 |
+200-250 |
|
Density (g/cm³) |
7.85 |
7.85 |
7.85 |
7.85 |
7.85 |
|
Apps |
Light frames |
Bridges |
Heavy structures |
Z35 offshore |
Ultra-heavy |
|
Gangsteel Stock |
High |
V. High |
High |
Highest |
Limited |
S460ML+Z35 "Z35 enhanced high strength"; vs S355ML, 30% higher yield; vs S460M, –50 °C KV; vs –20 °C; vs S500ML, better ductility/weldability. See S460M vs S460ML EN 10025-4 Impact Comparison Supplier.
Equivalent International Grades
Z35 equivs.
|
Standard |
Equivalent Grade |
Key Match Notes |
Typical Use Case |
|---|---|---|---|
|
ASTM/ASME |
A913 Gr.65 + Z35 |
Yield 450 MPa; Z35 –50 °C |
U.S. Z35 high-rise |
|
JIS G 3106 |
SM570 + Z35 |
Rm 570 MPa; ductility Z35 |
Japanese Z35 offshore |
|
GB/T 1591 |
Q460E + Z35 |
Low-temp Z35 |
China-EN Z35 projects |
|
API 2W |
Grade 60 + Z35 |
Offshore Z35 KV |
Z35 platforms |
|
EN 10025-6 |
S460QL + Z35 |
QT Z35; S460ML cheaper |
Heavy Z35 lifts |
Indicative; TMCP Z35 better. Dual-cert. Full: S460ML Equivalent Material EN 10025-4 Plate Supplier.
Applications & Design Considerations for S460ML+Z35
Z35 for Eurocode 3, 25-30% less steel in welds.
- Offshore: Jackets, Z35 tears; fatigue 10^8 cycles 140 MPa DNV-RP-C203.
- Seismic: Braces, enhanced KV; HIC Class 1.
- Pipes: Penstocks, A5 3% drifts EN 1998-1; C4M <0.08 mm/yr epoxy.
- Fab: T-joints, 3t radius; 55 yr ICCP.
Notes: Interpass 150°C; ER50-2. FEA Z35 properties, 2% hardening. Eco: 97% recycle, 20% CO2 save. Gangsteel V-50°, UT S4. For weld, S355ML/NL Weldability EN 10025-4 Fine Grain Supplier; data S355ML Data Sheet EN 10025-4 Steel Properties Supplier.
Why Choose Gangsteel for S460ML+Z35
- 4,000+ t Z35 stock.
- Mill-direct 80-140 USD/t save; >700 MT tiers.
- Process: laser ±0.3 mm, X-bevel, 150 mm bore, 450 mm roll, C5H 200 µm.
- Cert: ISO 9001/14001, NACE sour, EN 1090 EXC4.
- Legacy: Siemens 1,200+ t Z35 (Hornsea), Total (Ichthys)—OTIF 100%.
To 92+ countries: Rotterdam 6 days. For specs, S355ML Specification EN 10025-4 Steel Plate Supplier; comparison S355ML vs S355J2 EN 10025-4 Strength Comparison Supplier.
Summary
S460ML+Z35 EN 10025-4 plates from Gangsteel provide guaranteed Z35 through-thickness ductility (RA_z ≥35%), 460 MPa yield, –50 °C toughness, and TMCP weldability for critical structural welds in offshore, seismic, and heavy fabrication. Stocked in 6–200 mm with full certification, Z35 eliminates lamellar tearing risk where standard Z25 fails. Contact for immediate supply.
FAQ
Q1: What is Z35 in S460ML?
A: Z35 = ≥35% reduction of area in Z-direction tensile test (EN 10164 Cl.3), preventing lamellar tearing in welds under perpendicular stress. Mandatory for T-joints in offshore jackets.
Q2: S460ML+Z35 vs S460ML difference?
A: Z35 adds through-thickness guarantee (RA_z ≥35%); standard S460ML is Z25 (≥25%). Yield/impact same—Z35 for high-risk welds.
Q3: Welding preheat for S460ML+Z35?
A: None to 80 mm (CEV 0.42-0.46); low-H E7018 H4. Thicker: 75-120 °C (EN ISO 13916). TMCP preserves Z35 in HAZ.
Q4: S460ML+Z35 for pressure vessels?
A: Yes, PED III (EN 13445); derate >63 mm. UT S3/E3; RT opt seams. Z35 aids nozzle welds.
Q5: Z35 price premium?
A: +20-40 USD/t vs standard S460ML; included in our Z35 stock.
Q6: ASTM equiv for S460ML+Z35?
A: A913 Gr.65 + Z35; yield 450 MPa, Z35 –50 °C. Dual-cert stocked.
Q7: Custom S460ML+Z35 lead time?
A: Stock 1-3 days; processed 2-5 days; mill 3-5 weeks. 95% OTIF; air <10 MT 24-48 hrs.
