Material S460ML EN 10025-4 Fine Grain Steel Supplier

Material S460ML EN 10025-4 Fine Grain Steel Supplier

Gangsteel – China's Largest Mill-Direct Supplier & Exporter of Material S460ML EN 10025-4 Fine Grain Steel Plates

Gangsteel is the professional and most reliable supplier for Material S460ML EN 10025-4 fine grain steel plates, with the largest permanent stock in Asia – over 5,000 tons always ready in thickness 6–200 mm, width 1500–4200 mm, length up to 18 meters. All plates are genuine TMCP (thermomechanical controlled process) fine grain produced by top Chinese mills (HBIS, Shougang, Nanjing Steel) with full European approvals (PED 2014/68/EU, CPR 305/2011).

We supply with original EN 10204-3.1/3.2 certificates and third-party inspection (DNV-GL, ABS, LR, BV, CCS, KR, TÜV, SGS). Z25/Z35 through-thickness quality in stock, 100 % ultrasonic testing EN 10160 S2/E2 standard.

Immediate delivery worldwide in 3–7 days. Full processing services: plasma/oxy cutting, beveling, drilling, rolling, priming.

Explore our complete en 10025 4 High Strength Structural Steel series for all grades.

What is Material S460ML EN 10025-4 Fine Grain Steel?

Material S460ML is a thermomechanically rolled (TMCP) weldable fine grain structural steel specified in EN 10025-4:2004 (current version 2019).

The designation “S460ML” means:

• S= structural steel
• 460= minimum yield strength 460 MPa (transverse, thickness ≤ 16 mm)
• M= thermomechanical rolling (TMCP delivery condition)
• L= low-temperature impact toughness (–50 °C test)

The fine grain structure is achieved through controlled microalloying (Nb, V, Ti) and the TMCP process, resulting in ASTM grain size 8–11. This is what gives S460ML its excellent combination of very high strength, superior low-temperature toughness, and outstanding weldability.

S460ML is the highest-strength low-temperature grade in the EN 10025-4 family that still offers excellent weldability and formability. It is the material of choice when maximum strength-to-weight ratio and –50 °C performance are required.

Chemical Composition – Ladle Analysis (max % unless noted)

Typical Gangsteel actual values: C 0.10–0.14 %, CEV 0.42–0.46 → excellent weldability without preheating up to 80 mm thickness.

Mechanical Properties – Full Thickness Range up to 200 mm (transverse values)

*Gangsteel guarantees higher values in thick plates by agreement.

Hardness: 160–210 HBW Density: 7.85 g/cm³

Available Specifications & Testing

• Thickness: 6–200 mm (20–150 mm most popular in stock)
• Width: 1500–4200 mm
• Length: up to 18 000 mm
• Z-quality: Z25 standard, Z35 large stock
• NDT: 100 % ultrasonic testing EN 10160 S2/E2 (S3/E3 optional)
• Surface: shot-blasted + primer or mill finish
• Certification: EN 10204-3.1/3.2, PED, CPR, all major class approvals

Applications of S460ML Fine Grain Material

S460ML is widely used when maximum strength and low-temperature toughness are required:

• Offshore wind turbine monopiles and jackets
• Arctic oil & gas platforms
• Jack-up rigs and heavy lifting equipment
• High-rise building columns
• Cold-region bridges and infrastructure

Why Choose Gangsteel for S460ML Fine Grain Material

• Largest S460ML fine grain stock in Asia (5,000+ tons ready)
• Factory-direct price – 60–120 USD/ton lower than traders
• Full processing capability (cutting, beveling, drilling, rolling, priming)
• Z35 quality always in stock
• Immediate delivery worldwide
• Exported to 90+ countries with perfect documentation
• One-stop service – stock → processing → shipping

FAQ – Detailed Answers

Q1: What makes S460ML "fine grain"?

A: The combination of low carbon, Al + Nb + V + Ti microalloying, and TMCP process produces ASTM grain size 8–11, which is the definition of "fine grain" and the reason for its superior toughness and weldability.

Q2: S460ML vs S460M difference?

A: The only difference is the impact test temperature. S460ML is tested at –50 °C with minimum 27 J (longitudinal), while S460M is tested at –20 °C with minimum 40 J. Yield strength, tensile strength, elongation, chemical composition, and weldability are exactly the same.

Q3: Is preheating required when welding S460ML?

A: No preheating is required up to 80 mm thickness thanks to the very low CEV (typically 0.42–0.46 actual). For thicknesses over 80 mm or highly restrained joints, a modest preheat of 75–100 °C is sufficient.

Q4: Do you have Z35 quality in stock for S460ML?

A: Yes – we keep very large stock of S460ML + Z35 (reduction of area ≥35 % per EN 10164 Class 3), especially in 20–150 mm thickness, ready for immediate delivery.

Q5: What is the density and hardness of S460ML?

A: Density is 7.85 g/cm³ (7850 kg/m³), hardness is 160–210 HBW (typical 170–190 HBW in our stock). These values are consistent across the entire thickness range.

Q6: What NDT do you provide as standard?

A: 100 % ultrasonic testing to EN 10160 S2/E2 is included with every plate. We can upgrade to S3/E3, magnetic particle (MT), or penetrant testing (PT) on request at no extra charge for reasonable quantities.

Q7: How fast can you deliver to Europe or USA?

A: From ready stock: 7–12 days to Rotterdam, Antwerp, Houston, or Los Angeles. We have regular consolidation containers and can offer air freight for urgent small quantities (<10 tons) in 48–72 hours.

Contact Gangsteel Today

Need S460ML fine grain material? Contact us now for best price and fastest delivery.

Email: admin@gangsteel.com WhatsApp/WeChat/Mobile: +86 135 9887 9167 Website: https://gangsteel.net/

Gangsteel – Real Factory. Real Stock. Real Fast Delivery.
