Gangsteel – China's Leading Mill-Direct Supplier & Exporter of Steel S460ML EN 10025-4 High Strength Plates
Gangsteel is the professional supplier you can trust for steel S460ML EN 10025-4 high strength plates, with the largest permanent stock in Asia – over 5,000 tons always ready in thickness 6–200 mm, width 1500–4200 mm, length up to 18 meters. All plates are genuine TMCP (thermomechanical controlled process) produced by top Chinese mills (HBIS, Shougang, Nanjing Steel) with full European approvals (PED 2014/68/EU, CPR 305/2011).
We supply with original EN 10204-3.1/3.2 certificates and third-party inspection (DNV-GL, ABS, LR, BV, CCS, KR, TÜV, SGS). Z25/Z35 through-thickness quality in stock, 100 % ultrasonic testing EN 10160 S2/E2 standard.
Immediate delivery worldwide in 3–7 days. Full processing services: plasma/oxy cutting, beveling, drilling, rolling, priming.
Explore our complete en 10025 4 High Strength Structural Steel series for all grades, including the popular low-temperature grade en 10025 4 s460ml steel plate and the widely used en 10025 4 s355ml steel plate.
Steel S460ML is a thermomechanically rolled (TMCP) weldable fine-grain structural steel specified in EN 10025-4:2004 (current version 2019).
The designation “S460ML” means:
S460ML is the highest-strength low-temperature grade in the EN 10025-4 family that still offers excellent weldability and formability. It is the material of choice when maximum strength-to-weight ratio and –50 °C performance are required.
|
Element |
C |
Si |
Mn |
P |
S |
Nb |
V |
Al min |
Ti |
Cr |
Ni |
Mo |
Cu |
N |
CEV max |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
S460ML |
0.16 |
0.60 |
1.70 |
0.025 |
0.020 |
0.05 |
0.12 |
0.020 |
0.05 |
0.30 |
0.80 |
0.20 |
0.55 |
0.025 |
0.48 |
Typical Gangsteel actual values: C 0.10–0.14 %, CEV 0.42–0.46 → excellent weldability without preheating up to 80 mm thickness.
|
Thickness (mm) |
ReH min (MPa) |
Rm (MPa) |
A5 min (%) |
KV min (J) at –50 °C longitudinal |
|---|---|---|---|---|
|
≤ 16 |
460 |
540–720 |
17 |
27 |
|
>16 ≤ 40 |
440 |
540–720 |
17 |
27 |
|
>40 ≤ 63 |
430 |
540–720 |
17 |
27 |
|
>63 ≤ 80 |
410 |
540–720 |
17 |
27 |
|
>80 ≤ 100 |
400 |
540–720 |
17 |
27 |
|
>100 ≤ 120 |
385 |
530–710 |
17 |
27 |
|
>120 ≤ 150 |
370 |
530–710 |
17 |
27 |
|
>150 ≤ 200 |
350–380* |
530–710 |
17 |
27 |
*Gangsteel guarantees higher values in thick plates by agreement.
Hardness: 160–210 HBW Density: 7.85 g/cm³
S460ML is widely used when maximum strength and low-temperature toughness are required:
Q1: S460ML vs S460M difference?A: Only impact test temperature. S460ML = –50 °C (≥27 J), S460M = –20 °C (≥40 J). Strength, chemistry, weldability identical.
Q2: Preheating required?A: No preheat up to 80 mm thickness. >80 mm: 75–100 °C max.
Q3: Z35 availability?A: Yes – very large stock of S460ML + Z35 ready for immediate delivery.
Q4: Density and hardness?A: Density 7.85 g/cm³, hardness 160–210 HBW.
Q5: NDT standard?A: 100 % UT EN 10160 S2/E2 included. S3/E3, MT, PT on request.
Q6: Maximum thickness?A: Up to 200 mm with full properties and certification.
Q7: Delivery time?A: Stock material 3–7 days worldwide.
Need EN 10025-4 S460ML plates? Contact us now for best price and fastest delivery.
