Overview of S355ML and Its Japanese Equivalent SM490A

S355MLis a thermomechanically rolled, low-temperature, high-strength structural steel specified in EN 10025-4. It offers a minimum yield strength of 355 MPa and excellent toughness at low temperatures (–50°C typical), making it suitable for offshore, bridges, heavy machinery, and welded structures.

In the Japanese JIS G3106 standard, the closest comparable grade is SM490A, a weldable structural steel used for bridges, marine structures, and building frameworks.
Although SM490A is not fully identical to S355ML, engineers often treat them as practical equivalents in strength-level and application range.

Chemical Composition Comparison (S355ML vs JIS SM490A)

Element (%)	S355ML (EN 10025-4)	SM490A (JIS G3106)
C	≤ 0.16	≤ 0.18
Mn	1.00–1.70	1.00–1.60
Si	≤ 0.60	≤ 0.55
P	≤ 0.025	≤ 0.035
S	≤ 0.020	≤ 0.035
Nb / V / Ti	Allowed (micro-alloyed)	Not typical
CE (IIW)	≤ 0.43	≈ 0.45



Summary:

• S355ML has stricter P+S limits.
• S355ML uses TMCP and micro-alloying, giving better weldability and toughness.
• SM490A has slightly higher carbon and no mandatory low-temperature requirements.

Mechanical Properties Comparison

Property	S355ML (EN 10025-4)	SM490A (JIS G3106)
Yield Strength (ReH)	355 MPa (≤16mm)	325–355 MPa depending on thickness
Tensile Strength (Rm)	470–630 MPa	490–610 MPa
Elongation	≥ 22%	≥ 21%
Impact Energy	27J at –50°C	27J at +20°C
Delivery Condition	TMCP	As Rolled / Normalized

Summary:

• S355ML has superior low-temperature impact toughness.
• SM490A is suitable for general structural use but does not require low-temperature toughness testing.
• Strength levels are broadly similar, although S355ML is more reliable in extreme cold environments.

Application Comparison

Both grades are used in structural engineering, but S355ML is preferred for low-temperature service:

S355ML Typical Applications

• Offshore platforms
• LNG and low-temperature equipment
• Bridges
• High-rise structures
• Wind towers
• Heavy machinery
• Crane booms

SM490A Typical Applications

• Building structures
• Bridges
• General welded construction
• Marine structures
• Machinery parts

Are S355ML and SM490A Interchangeable?

Partially.

They are often considered equivalent when:

• The project requires ~355 MPa yield strength
• The environment is normal temperature
• Toughness requirements are moderate
• Plate thickness is within typical structural ranges

However, SM490A does not meet low-temperature impact requirements.
For cold regions, offshore structures, or –20°C / –40°C / –50°C service, S355ML is the correct material.

Gangsteel Supply Range

We supply both S355ML and JIS SM490A with:

• Thickness: 6–200 mm
• Width: 1500–3500 mm
• Length: 6000–12000 mm
• UT Testing: EN10160 or JIS ultrasonic levels
• Impact test: –20°C / –40°C / –50°C available for S355ML

Mill certificates: EN 10204 3.1 or 3.2.
