Gangsteel – China's Largest Mill-Direct Supplier & Exporter of S460M Material EN 10025-4 Fine Grain Plates

Gangsteel is the professional and most reliable supplier for S460M material EN 10025-4 fine grain plates, with the largest permanent stock in Asia – over 5,000 tons always ready in thickness 6–200 mm, width 1500–4200 mm, length up to 18 meters. All plates are genuine TMCP (thermomechanical controlled process) fine grain produced by top Chinese mills (HBIS, Shougang, Nanjing Steel) with full European approvals (PED 2014/68/EU, CPR 305/2011).

We supply with original EN 10204-3.1/3.2 certificates and third-party inspection (DNV-GL, ABS, LR, BV, CCS, KR, TÜV, SGS). Z25/Z35 through-thickness quality in stock, 100 % ultrasonic testing EN 10160 S2/E2 standard.

Immediate delivery worldwide in 3–7 days. Full processing services: plasma/oxy cutting, beveling, drilling, rolling, priming.

Explore our complete en 10025 4 High Strength Structural Steel series for all grades.

What is S460M Material EN 10025-4 Fine Grain Steel?

S460M material is a thermomechanically rolled (TMCP) weldable fine grain structural steel specified in EN 10025-4:2004 (current version 2019).

The designation “S460M” means:

• S= structural steel
• 460= minimum yield strength 460 MPa (transverse, thickness ≤ 16 mm)
• M= thermomechanical rolling (TMCP delivery condition)

The fine grain structure is achieved through controlled microalloying (Nb, V, Ti) and the TMCP process, resulting in ASTM grain size 8–11. This is what gives S460M its excellent combination of very high strength, superior weldability, and good low-temperature toughness (≥40 J at –20 °C).

S460M is the highest-strength standard-temperature grade in the EN 10025-4 family. It is the direct TMCP alternative to normalized S460N (EN 10025-3) and the sister grade to the low-temperature bestseller S460ML (–50 °C).

Chemical Composition – Ladle Analysis (max % unless noted)

Typical Gangsteel actual values: C 0.10–0.14 %, CEV 0.42–0.46 → excellent weldability without preheating up to 80 mm thickness.

Mechanical Properties – Full Thickness Range up to 200 mm (transverse values)

*Gangsteel guarantees higher values in thick plates by agreement.

Hardness: 160–210 HBW Density: 7.85 g/cm³

Available Specifications & Testing

• Thickness: 6–200 mm (20–150 mm most popular in stock)
• Width: 1500–4200 mm
• Length: up to 18 000 mm
• Z-quality: Z25 standard, Z35 large stock
• NDT: 100 % ultrasonic testing EN 10160 S2/E2 (S3/E3 optional)
• Surface: shot-blasted + primer or mill finish
• Certification: EN 10204-3.1/3.2, PED, CPR, all major class approvals

Applications of S460M Fine Grain Material

S460M is widely used when maximum strength and good toughness are required:

• High-rise building columns
• Heavy crane booms and lifting equipment
• Onshore wind turbine towers
• Heavy machinery bases
• Shipbuilding and marine structures (non-Arctic)

When the temperature drops below –20 °C, the low-temperature version S460ML is required.

Why Choose Gangsteel for S460M Fine Grain Material

• Largest S460M fine grain stock in Asia (5,000+ tons ready)
• Factory-direct price – 60–120 USD/ton lower than traders
• Full processing capability (cutting, beveling, drilling, rolling, priming)
• Z35 quality always in stock
• Immediate delivery worldwide
• Exported to 90+ countries with perfect documentation
• One-stop service – stock → processing → shipping

FAQ – Quick Answers

Q1: What makes S460M "fine grain"?A: The combination of low carbon, Al + Nb + V + Ti microalloying, and TMCP process produces ASTM grain size 8–11, which is the definition of "fine grain" and the reason for its superior toughness and weldability.

Q2: S460M vs S460ML difference?A: Only impact test temperature. S460ML = –50 °C (≥27 J), S460M = –20 °C (≥40 J). Strength, chemistry, weldability identical.

Q3: Preheating required?A: No preheat up to 80 mm thickness. >80 mm: 75–100 °C max.

Q4: Z35 availability?A: Yes – very large stock of S460M + Z35 ready for immediate delivery.

Q5: Density and hardness?A: Density 7.85 g/cm³, hardness 160–210 HBW.

Q6: NDT standard?A: 100 % UT EN 10160 S2/E2 included. S3/E3, MT, PT on request.

Q7: Maximum thickness?A: Up to 200 mm with full properties and certification.

Contact Gangsteel Today

Need S460M fine grain material? Contact us now for best price and fastest delivery.

Email: admin@gangsteel.com WhatsApp/WeChat/Mobile: +86 135 9887 9167 Website: https://gangsteel.net/

Gangsteel – Real Factory. Real Stock. Real Fast Delivery.

EN 10025-4 S460M Steel plate other property
