Gangsteel – China's Leading Mill-Direct Supplier & Exporter of S460M+Z35 EN 10025-4 Z35 Through-Thickness Plates

Gangsteel is the professional supplier you can trust for S460M+Z35 EN 10025-4 Z35 through-thickness plates, with the largest permanent stock in Asia – over 5,000 tons always ready in thickness 6–200 mm, width 1500–4200 mm, length up to 18 meters. All plates are genuine TMCP (thermomechanical controlled process) produced by top mills with full European approvals and third-party inspection (DNV-GL, ABS, LR, BV, CCS, KR, TÜV, SGS).

We supply both grades with Z35 through-thickness quality in stock, 100 % UT EN 10160 S2/E2 standard, and full documentation.

Explore our complete en 10025 4 High Strength Structural Steel series, including the popular low-temperature grade en 10025 4 s460ml steel plate and the widely used en 10025 4 s355ml steel plate, as well as the standard-temperature en 10025 4 s355m steel plate and en 10025 4 s460m steel plate.

What is S460M+Z35 EN 10025-4 Z35 Through-Thickness Plate?

S460M+Z35is a thermomechanically rolled (TMCP) weldable fine-grain structural steel under EN 10025-4:2004 (2019 revision) with additional Z35 through-thickness quality per EN 10164 Class 3.

• S460M= structural steel, 460 MPa yield, TMCP delivery, standard –20 °C impact
• +Z35= guaranteed through-thickness ductility: minimum 35 % reduction of area (RA_z) in Z-direction tensile test (three specimens per heat, average ≥35 %, single ≥25 %)

Z35 quality prevents lamellar tearing in highly stressed welded joints where tension acts perpendicular to the plate surface (T-joints, cruciform welds, gusset plates, etc.).

S460M+Z35 is the preferred grade for:

• High-rise building columns
• Heavy crane base and boom sections
• Onshore wind turbine towers
• Heavy machinery under high Z-direction stress
• Shipbuilding and marine structures (non-Arctic)

When the temperature drops below –20 °C, the low-temperature version S460ML is required.

Chemical Composition – Ladle Analysis (max % unless noted)

Typical Gangsteel actual values: C 0.10–0.14 %, CEV 0.42–0.46 → excellent weldability without preheating up to 80 mm thickness.

Mechanical Properties – Full Thickness Range up to 200 mm (transverse values)

*Gangsteel guarantees higher values in thick plates by agreement.

Hardness: 160–210 HBW Density: 7.85 g/cm³

Available Specifications & Testing

• Thickness: 6–200 mm (20–150 mm most popular in stock)
• Width: 1500–4200 mm
• Length: up to 18 000 mm
• Z-quality: Z25 standard, Z35 large stock
• NDT: 100 % ultrasonic testing EN 10160 S2/E2 (S3/E3 optional)
• Surface: shot-blasted + primer or mill finish
• Certification: EN 10204-3.1/3.2, PED, CPR, all major class approvals

Applications of EN 10025-4 S460M Plates

S460M is widely used when maximum strength is required:

• High-rise building columns
• Heavy crane booms and lifting equipment
• Onshore wind turbine towers
• Heavy machinery bases
• Shipbuilding and marine structures (non-Arctic)

When the temperature drops below –20 °C, the low-temperature version S460ML is required.

Why Choose Gangsteel for S460M Plates

• Largest S460M stock in Asia (5,000+ tons ready)
• Factory-direct price – 60–120 USD/ton lower than traders
• Full processing capability (cutting, beveling, drilling, rolling, priming)
• Z35 quality always in stock
• Immediate delivery worldwide
• Exported to 90+ countries with perfect documentation
• One-stop service – stock → processing → shipping

FAQ – Detailed Answers

Q1: What is the difference between S460M and S460ML?

A: The only difference is the impact test temperature. S460M is tested at –20 °C with minimum 40 J (longitudinal), while S460ML is tested at –50 °C with minimum 27 J. Yield strength, tensile strength, elongation, chemical composition, and weldability are exactly the same.

Q2: Is preheating required when welding S460M?

A: No preheating is required up to 80 mm thickness thanks to the very low CEV (typically 0.42–0.46 actual). For thicknesses over 80 mm or highly restrained joints, a modest preheat of 75–100 °C is sufficient.

Q3: Do you have Z35 quality in stock for S460M?

A: Yes – we keep very large stock of S460M + Z35 (reduction of area ≥35 % per EN 10164 Class 3), especially in 20–150 mm thickness, ready for immediate delivery.

Q4: What is the density and hardness of S460M?

A: Density is 7.85 g/cm³ (7850 kg/m³), hardness is 160–210 HBW (typical 170–190 HBW in our stock). These values are consistent across the entire thickness range.

Q5: What NDT do you provide as standard?

A: 100 % ultrasonic testing to EN 10160 S2/E2 is included with every plate. We can upgrade to S3/E3, magnetic particle (MT), or penetrant testing (PT) on request at no extra charge for reasonable quantities.

Q6: What is the maximum thickness you can supply for S460M?

A: Up to 200 mm with full properties and certification. We guarantee minimum yield of 380 MPa up to 180 mm and 350 MPa to 200 mm – significantly better than the standard requirement.

Q7: How fast can you deliver to Europe or USA?

A: From ready stock: 7–12 days to Rotterdam, Antwerp, Houston, or Los Angeles. We have regular consolidation containers and can offer air freight for urgent small quantities (<10 tons) in 48–72 hours.

Contact Gangsteel Today

Need EN 10025-4 S460M plates? Contact us now for best price and fastest delivery.

Email: admin@gangsteel.com WhatsApp/WeChat/Mobile: +86 135 9887 9167 Website: https://gangsteel.net/

Gangsteel – Real Factory. Real Stock. Real Fast Delivery.
