Steel S460M EN 10025-4 High Strength Plate Supplier

Steel S460M EN 10025-4 High Strength Plate Supplier

Gangsteel – China’s Largest Mill-Direct Supplier & Exporter of Steel S460M EN 10025-4 High Strength Plates

Gangsteel is the professional supplier you can trust for steel S460M EN 10025-4 high strength plates, with the largest permanent stock in Asia – over 5,000 tons always ready in thickness 6–200 mm, width 1500–4200 mm, length up to 18 meters. All plates are genuine TMCP (thermomechanical controlled process) produced by top mills with full European approvals and third-party inspection (DNV-GL, ABS, LR, BV, CCS, KR, TÜV, SGS).

Steel S460M is the high-strength grade in the en 10025 4 High Strength Structural Steel family, offering 460 MPa minimum yield strength and ≥40 J impact toughness at –20 °C. It is the direct TMCP alternative to normalized S460N (EN 10025-3) and the sister grade to the low-temperature bestseller S460ML (–50 °C).

We also stock the complete EN 10025-4 series, including the popular low-temperature grade en 10025 4 s460ml steel plate and the widely used en 10025 4 s355ml steel plate, as well as the standard-temperature en 10025 4 s355m steel plate.

What is Steel S460M EN 10025-4 High Strength Plate?

Steel S460M is a thermomechanically rolled (TMCP) weldable fine-grain high-strength structural steel specified in EN 10025-4:2004 (current version 2019).

The designation “S460M” means:

• S= structural steel
• 460= minimum yield strength 460 MPa (transverse, thickness ≤ 16 mm)
• M= thermomechanical rolling (TMCP delivery condition)

The TMCP process – controlled hot rolling + accelerated cooling – produces a very fine-grained microstructure without separate normalizing heat treatment. This gives steel S460M:

• Higher strength-to-weight ratio than standard grades
• Lower residual stress
• Better flatness and dimensional stability
• Excellent weldability (CEV ≤ 0.48)
• Better fatigue performance and HAZ toughness

Steel S460M is the highest-strength standard-temperature grade in the EN 10025-4 family. It is the direct TMCP alternative to normalized S460N (EN 10025-3) and the sister grade to the low-temperature bestseller S460ML (–50 °C).

Steel S460M plates are widely used in applications requiring maximum strength without extreme low-temperature demands, such as high-rise building columns, heavy crane booms, lifting equipment, and onshore wind turbine towers. The material's fine grain structure from TMCP ensures consistent performance even in thick sections, making it ideal for cost-effective designs under Eurocode 3 (EN 1993-1-1).

Gangsteel's steel S460M plates are produced with ultra-low sulfur (S ≤ 0.010%) for Z35 quality, ensuring no lamellar tearing in critical welded joints. Our plates have typical actual yield strengths 10–20% above minimum, providing an extra safety margin.

Chemical Composition – Ladle Analysis (max % unless noted)

Typical Gangsteel actual values: C 0.10–0.14 %, CEV 0.42–0.46 → excellent weldability without preheating up to 80 mm thickness.

Mechanical Properties – Full Thickness Range up to 200 mm (transverse values)

*Gangsteel guarantees higher values in thick plates by agreement.

Hardness: 160–210 HBW Density: 7.85 g/cm³

Available Specifications & Testing

• Thickness: 6–200 mm (20–150 mm most popular in stock)
• Width: 1500–4200 mm
• Length: up to 18 000 mm
• Z-quality: Z25 standard, Z35 large stock
• NDT: 100 % ultrasonic testing EN 10160 S2/E2 (S3/E3 optional)
• Surface: shot-blasted + primer or mill finish
• Certification: EN 10204-3.1/3.2, PED, CPR, all major class approvals

Applications of Steel S460M High Strength Plates

Steel S460M is widely used when maximum strength is required:

• High-rise building columns
• Heavy crane booms and lifting equipment
• Onshore wind turbine towers
• Heavy machinery bases
• Shipbuilding and marine structures (non-Arctic)

When the temperature drops below –20 °C, the low-temperature version S460ML is required.

Why Choose Gangsteel for Steel S460M Plates

• Largest steel S460M stock in Asia (5,000+ tons ready)
• Factory-direct price – 60–120 USD/ton lower than traders
• Full processing capability (cutting, beveling, drilling, rolling, priming)
• Z35 quality always in stock
• Immediate delivery worldwide
• Exported to 90+ countries with perfect documentation
• One-stop service – stock → processing → shipping

FAQ – Quick Answers

Q1: Steel S460M vs S460ML difference?A: Only impact test temperature. S460ML = –50 °C (≥27 J), S460M = –20 °C (≥40 J). Strength, chemistry, weldability identical.

Q2: Preheating required?A: No preheat up to 80 mm thickness. >80 mm: 75–100 °C max.

Q3: Z35 availability?A: Yes – very large stock of steel S460M + Z35 ready for immediate delivery.

Q4: Density and hardness?A: Density 7.85 g/cm³, hardness 160–210 HBW.

Q5: NDT standard?A: 100 % UT EN 10160 S2/E2 included. S3/E3, MT, PT on request.

Q6: Maximum thickness?A: Up to 200 mm with full properties and certification.

Q7: Delivery time?A: Stock material 3–7 days worldwide.

Contact Gangsteel Today

Need steel S460M high strength plates? Contact us now for best price and fastest delivery.

Email: admin@gangsteel.com WhatsApp/WeChat/Mobile: +86 135 9887 9167 Website: https://gangsteel.net/

Gangsteel – Real Factory. Real Stock. Real Fast Delivery.
