Gangsteel supplies 430 stainless steel (AISI 430 / UNS S43000) in full compliance with the leading international standards. We produce sheet, coil, plate, and strip to any of the following specifications:
|
Element |
Content (wt%) |
|---|---|
|
Carbon (C) |
≤ 0.12 |
|
Chromium (Cr) |
16.00 – 18.00 |
|
Manganese (Mn) |
≤ 1.00 |
|
Silicon (Si) |
≤ 1.00 |
|
Phosphorus (P) |
≤ 0.040 |
|
Sulfur (S) |
≤ 0.030 |
|
Nickel (Ni) |
≤ 0.75 |
|
Iron (Fe) |
Balance |
|
Property |
Minimum Value |
Typical Range |
|---|---|---|
|
Yield Strength (0.2% offset) |
≥ 205 MPa |
220 – 280 MPa |
|
Tensile Strength |
≥ 450 MPa |
450 – 600 MPa |
|
Elongation (50 mm gauge) |
≥ 22% |
25 – 35% |
|
Hardness (Rockwell B) |
≤ 89 HRB |
80 – 88 HRB |
|
Hardness (Brinell) |
≤ 183 HB |
150 – 180 HB |
|
Property |
Value |
|---|---|
|
Density |
7.70 g/cm³ |
|
Thermal Conductivity (20–100 °C) |
26.0 – 26.5 W/m·K |
|
Thermal Expansion (0–100 °C) |
10.5 × 10⁻⁶/°C |
|
Modulus of Elasticity |
200 GPa |
|
Specific Heat (20 °C) |
460 J/kg·K |
|
Electrical Resistivity |
600 μΩ·cm |
|
Magnetic |
Yes (ferritic) |
All material is supplied with full mill test certificates (EN 10204 3.1 or 3.2) and third-party inspection (SGS, TUV, BV) upon request.
For detailed product pages and specifications, please see:
Contact our technical sales team for current pricing, samples, custom sizes, or mill test certificates. Gangsteel is your reliable partner for 430 stainless steel worldwide.
